11. CRANKCASE / CRANK

General information

Operational precautions
● This Section concerns disassembly of the crankcase for repair purpose.
● Remove following components before disassembling crankcase.
－Engine remove
－Cylinder head
－Cylinder and piston
－Drive face and driven pulley
－AC generator/Start one way clutch
● In case it requires replacing the crankshaft bearing, the driving chain of engine oil pump or the timing
chain, it is preferably to replace crankshaft as a unit.
Specification
Unit: mm
Connecting rod side clearance of the big end
Crankshaft
Vertical clearance of the big end of the connecting rod
Run-out
Torque value
Bolts for crankcase
Engine oil drain bolt
Cylinder stud bolt
Tools
Special tools
L. crank shaft oil seal driver (27*42*7):

Trouble diagnosis

Engine noise
● Loose crankshaft bearing
● Loose crankshaft pin bearing
● Worn out piston pin and pin hole
