Polycom VVX Business Media Phones User Guide

Connect Additional Expansion Modules

After the first module is on, you can connect up to two additional modules to your VVX phone.
To connect multiple VVX Expansion Modules:
1 Connect an auxiliary cable from the AUX 2 port on the first module connected to the phone to the
AUX 1 port on the second module.
2 Connect an auxiliary cable from the AUX 2 port on the second module to the AUX 1 port on the third
module.
The LED lights on the line keys light up for each connected module as the expansion modules start
up.

Using VVX Expansion Modules

This section includes the following topics on how to use the VVX Expansion Modules with your VVX phone:
●
Assigning Busy Lamp Field Contacts, Microsoft Skype for Business Contacts, and Favorites
●
Generate the VVX Expansion Module Directory Card
●
Navigate VVX Color Expansion Module Paging
●
Changing the Backlight Intensity
Assigning Busy Lamp Field Contacts, Microsoft Skype for Business Contacts, and
Favorites
The default view on your phone screen, which is the Lines screen, displays line registrations, busy lamp
field contacts, Microsoft Skype for Business presence contacts, and favorites. Each function occupies a
display space on the Lines screen. VVX phones support a maximum number of display spaces, which are
listed in the following table. When you reach the maximum number of display spaces on your phone, the
next function you add is assigned to the first available line on your expansion module.
Maximum Number of VVX Phone Display Spaces
VVX Phone Model
VVX 300/310
VVX 400/410
VVX 500
VVX 600
Note: Additional favorites and Skype for Business contacts display in your Contact Directory
After you fill all the display spaces on your phone and assign functions to all the lines on your
expansion module, you can find additional favorites or Skype for Business contacts in the Contact
Directory.
Polycom, Inc.
Maximum Display Spaces Supported
6
12
12
16
207
