Ê Reconfigure your network settings in the operation system according to the
original configuration of the replaced controller (expansion card or onboard).
Ê Configuration of network settings should be performed by the customer.
9.9

External COM1 connector

9.9.1

Installing the external COM1 connector

Upgrade and Repair Unit
(URU)
Tool: – flat screw driver
– hexagon screw driver 5 mm
9.9.1.1

Preliminary steps

"Disabling SVOM boot watchdog functionality" on page 70
Ê
"Shutting down the server" on page 53
Ê
"Disconnecting power cords" on page 54
Ê
"Getting access to the component" on page 55
Ê
RX2540 M1
Upgrade and Maintenance Manual
Expansion cards and backup units
Hardware: 5 minutes
265
