Chapter 4
LinePrinter+ Emulation (N7000 STD)

Print Char. Set

When this selection is displayed and the ENTER key is pressed, the current
character set is printed.
Reset Cmd CFG Ld
When the printer receives a host data stream reset command
(ESC @ or ESC[K) in addition to resetting printer variables, the selected
configuration is loaded.
•
Disable (default). The active emulation parameters are loaded when the
reset command is executed.
•
Power-Up Config. The power-up configuration is loaded when the reset
command is executed.
•
Current Config. The currently selected configuration is loaded when the
reset command is executed.
•
Factory Config. The factory installed configuration is loaded when the
reset command is executed.

Set Substitution

When this option is activated, the character set overlay in RAM is activated.
This can also be accomplished through a host command of SFCC RX. In
either case, a flag is set indicating that the substitution table is active. If the
power-up configuration has Ld Set at Pwrup and Set Substitution both
enabled, the character set overlay is automatically activated at power-up or
during a soft reset. See the LinePrinter Plus Programmer's Reference Manual
for more information.
Barcode x-Offset
•
Disable (default)
•
Enable. Allows text to print next to a barcode when xxxx and yyyy are not
set to the origin.
