View Firmware Version - HP STORAGEWORKS SSL1016 Reference Manual

View Firmware Version

To view the firmware version:
1. On the main menu, scroll to Status. (See
2. Press Enter.
3. On the Status submenu, scroll to Autoloader Info. (See
4. Press Enter.
5. On the autoloader Info submenu, scroll to Version. (See
6. Press Enter.
Figure 65: Autoloader version messages
Table 9: Autoloader Version Messages
Firmware
EDC
HW Rev
ME Rev
SSL1016 Tape Autoloader Reference Guide
A list of messages similar to the following screen appears.
Firmware: V7.0
EDC: 575A49B8
HW + ME Rev: 1 1
The number indicates the firmware version.
The number indicates the Error Detection Code that
was generated when the firmware was installed. The
autoloader uses this number to verify that the firmware
and the memory holding the firmware are good.
The number indicates the hardware version.
The number indicates the mechanical version.
Autoloader Operation
Figure 61.)
Figure
Figure
62.)
63.)
91
