QuickSpecs
Overview
Is finding reliable DRAM memory for your HP ProLiant Server series in your data center a major challenge?
When you choose HP SmartMemory you get the same high quality, reliability, and confidence that come with your HP ProLiant Gen8
Server series. DRAM quality and reliability are more important now than ever. Industry trends such as server virtualization, cloud
computing, the use of large database applications and high-performance computing have all increased the need for higher capacity
memory with greater reliability and uptime. HP SmartMemory is unique technology introduced for ProLiant Gen8 Servers that unlocks
certain features available only with HP Qualified Server memory. HP SmartMemory enables ProLiant Gen8 systems to reliably identify
and verify whether installed memory has passed the rigorous HP qualification and testing processes. And because the memory is
authenticated, extended memory performance features can be enabled through the system ROM.
What's New
HP SmartMemory 2GB, 4GB, 8GB, 16GB and 32GB @ 1866
HP SmartMemory 2GB, 4GB, 8GB, and16GB @ 1600 at Low voltage (1.35v)
HP SmartMemory 32GB HDIMM@1333
Models
Memory for Intel Servers
Registered DIMMs (RDIMMs)
HP 4GB (1x4GB) Single Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low Voltage Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low Voltage Memory Kit
HP 8GB (1x8GB) Single Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low Voltage Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit
HP 8GB (1x8GB) Single Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit
HP 16GB (1x16GB) Dual Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low Voltage Memory Kit
HP 16GB (1x16GB) Dual Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit
HP 24 GB (1x24GB) Three Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low Voltage FIO Memory Kit
NOTE: This is a Factory Installed Option (FIO) only.
HP 4GB (1x4GB) Single Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low Voltage Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low Voltage Memory Kit
HP 8GB (1x8GB) Single Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory Kit
DA - 14225 Worldwide — Version 11 — October 8, 2013
HP SmartMemory
713981-B21
708637-B21
713983-B21
731765-B21
708639-B21
731761-B21
713985-B21
708641-B21
716324-B21
647893-B21
647895-B21
647897-B21
647899-B21
Page 1
Advertisement
Related Manuals for HP SmartMemory
Summary of Contents for HP SmartMemory
- Page 1 Is finding reliable DRAM memory for your HP ProLiant Server series in your data center a major challenge? When you choose HP SmartMemory you get the same high quality, reliability, and confidence that come with your HP ProLiant Gen8 Server series. DRAM quality and reliability are more important now than ever. Industry trends such as server virtualization, cloud computing, the use of large database applications and high-performance computing have all increased the need for higher capacity memory with greater reliability and uptime.
- Page 2 647901-B21 HP 16GB (1x16GB) Dual Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory Kit 672631-B21 HP 24GB (1x24GB) Three Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low Voltage FIO Memory Kit 700404-B21 NOTE: This is a Factory Installed Option (FIO) only. Unbuffered with ECC DIMMs (UDIMMs)
-
Page 3: Standard Features
HP SmartMemory Standard Features What is HP SmartMemory? HP SmartMemory is unique technology introduced for ProLiant Gen8 servers that unlocks certain features available only with HP Qualified Server memory. HP SmartMemory enables ProLiant Gen8 systems to reliably identify and verify whether installed memory has passed HP's rigorous qualification and test processes. - Page 4 For more information on the HP Advanced Memory Error Detection Technology: http://h20000.www2.hp.com/bc/docs/support/SupportManual/c02878598/c02878598.pdf HP Active Health System Future ROM updates will enable HP SmartMemory to will work in conjunction with HP Active Health System which monitors changes to the server hardware configuration to enable lifecycle monitoring of memory health status.
- Page 5 Will there be unique part numbers for Intel and AMD supported HP ProLiant servers? HP has different part numbers for AMD and Intel servers because there are slight timing differences in the memory controllers which can lead to different list of qualified parts.
-
Page 6: Service And Support
Protect your business beyond warranty with HP Care Pack Services When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care Pack services provide total care and support expertise with committed response choices designed to meet your IT and business need. - Page 7 Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to return the hardware in operating condition within 6 hours of the initial service request to the HP Global Solution Center, and basic software problem diagnosis, fault isolation, and resolution if available to HP. In case, the issue is with HP or supported third-party software product and cannot be resolved by applying known fixes, HP will contact the third-party vendor and create a problem incident on your behalf.
- Page 8 The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating manual or the technical data sheet are not eligible for the defective media retention service feature option.
-
Page 9: Technical Specifications
(24) DIMMs for the server. Up to 32GB capacity DIMMs are supported for 768GB of memory (24 DIMM slots x 32GB per DIMM). For platform specific memory details please refer to the HP ProLiant user guide at: http://www.hp.com/support. General Memory Population Rules and Guidelines: Install DIMMs only if the corresponding processor is installed. -
Page 10: Maximum Capacity
HP SmartMemory Technical Specifications The Intel Xeon E5-2620 processor model does not support DIMMs at 1.35V. The system will default to 1.5V operation. Intel Gen8 Supported Memory Bandwidth for HP ProLiant Gen8 Intel® Xeon® E5-2XXX v2 Series Processor Family DIMM Load Type ->... - Page 11 Memory speed is a function of the processor QPI bus speed. * Maximum capacity will vary based on individual server platform qualification schedule For HP SmartMemory, UDIMM is supported at 2DPC@DDR3-1866. Third party memory may only support up to 2DPC@DDR3-1333 or 1600.
- Page 12 ** For HP SmartMemory, RDIMM support 3DPC@ DDR3-1066 at 1.35V. Third party memory may only support up to 3DPC@DDR3-1066 at 1.5V. *** LRDIMM enables 3 DIMMs per channel. HP SmartMemory will support up to 3DPC@DDR3-1066 at 1.35V. Third party memory may only support 3DPC @DDR3-1066 at 1.5V.
- Page 13 Ultra Low Voltage 8GB and 16GB dual rank operate at 800MT/s speed in 3 DPC configurations. LRDIMM capable of 3 DIMMs per channel. Memory Speed by Processor Model HP ProLiant Gen8 Intel® Xeon® E5-2600 Series Processor Family: Processor Models Supported Memory Speeds...
- Page 14 E5-2450L, E5-2440, E5-2430, E5-2420 1333/1066MHz E5-2430L, E5-2407, E5-2403 1066MHz HP ProLiant Gen8 Intel® Xeon® E5-2600 v2 Series Processor Family: Processor Models E5-2690 v2, E5-2680 v2, E5-2670 v2, E5-2660 v2, E5-2687W v2, E5-2667 v2, E5-2650 v2, E5- 2640 v2 E5-2643 v2, E5-2630 v2, E5-2620 v2, E5-2637 v2, E5-2609 v2, E5-2603 v2 E5-2605L v2, E5-2630L v2 HP ProLiant Gen8 Intel®...
- Page 15 The information contained herein is subject to change without notice. Xeon and Intel are registered trademarks of Intel Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
