Installing Telephones and
Adjuncts
The control unit supports the MLX-10, MLX-10D, MLX-10DP, MLX-20L, and
MLX-28D telephones, with or without Direct Station Selectors (DSSs), as well
as analog multiline and single-line telephones. It also supports various
adjuncts, which may require Multi-Function Modules (MFMs) or other adapters
for installation.
This chapter provides installation instructions for the following procedures:

Installing Multi-Function Modules

Installing adjuncts
Installing Direct Station Selectors
Assembling MLX telephones
Connecting telephones to the control unit
To connect data equipment to the system, see Chapter 6, "Connecting Data
Equipment." To connect the MERLIN PFC
Applications."
Installing Multi-Function Modules
The Multi-Function Module (MFM) is an optional adapter that provides a
modular jack connection to MLX telephones for the two classes of adjuncts
listed below:
see Chapter 8, "Installing
,

Installing Telephones and Adjuncts

3
3–1
