Connecting a PC to the Control Unit
Connecting a PC Within 50 Feet
Use this procedure to connect a PC to the control unit when the PC is within
50 ft. (15.2 m) of the control unit.
You need the following hardware for this procedure:
355AF adapter
D8W cord
EIA-232-D cable (optional)
To connect a PC within 50 ft. (15.2 m) of the control unit, follow the steps
below. See Figure 5–1.
1 Connect the D8W cord.
For system programming or maintenance, plug one end of a D8W cord
into the ADMIN jack on the control unit.
For SMDR, plug one end of a D8W cord into the SMDR jack on the
control unit.
2 Plug the other end of the D8W cord into a 355AF adapter.
3 Connect the 355AF adapter.
If you are using an EIA-232-D cable, plug one end of the cable into the
355AF adapter and plug the other end into the COM1 port on the PC.
If you are not using an EIA-232-D cable, plug the 355AF adapter
directly into the COM1 port on the PC.
