Call Management System

Hardware Requirements
The following hardware is required for CAT installation:
Call Accounting Terminal, CAT Plus
Serial printer (AT&T CAT Printer is recommended) connected by a
Z200A EMI cable to the PRINTER jack of the CAT
D8W cord and 355AF adapter connecting the SMDR port on the
communications system to the SMDR jack of the CAT
A summary of the installation procedure is provided below:
1 Before connecting the CAT, set the 10 CAT switches to establish the
speed or baud rate for the CAT and its associated printer.
2 Connect the control unit, CAT, printer, and power supply. See Chapter 5,
"Connecting a Printer to the Control Unit." Do not use an outlet that is
controlled by a wall switch.
3 Test the CAT Plus, following the instructions provided in the
documentation packaged with the application.
CAT Documentation
Call Accounting Terminal, CAT Plus V3 for Business Installation and Use
Call Accounting Terminal, CAT Plus V3 for Hospitality Installation and Use
Call Management System
Call Management System (CMS) is a DOS-based software application that
simulates the actions of a system operator by answering calls and distributing
them to individual telephones.
Installing Applications
8–9
