Connecting a Printer to the Control Unit
248B adapter
D8W cords
D6AP power cord
EIA-232-D cable
4-pair plug-ended cable
To connect a printer 50 ft. (15.2 m) or more away from the control unit, follow
the steps below. See Figure 5–6.
1 Plug the short end of a Z200A EMI cord into the SMDR jack on the control
unit.
2 Plug the other end of the Z200A EMI cord into a 355AF adapter.
3 Plug the female end of the 355AF adapter into one end of an EIA
crossover cable.
4 Plug the other end of the EIA cable into the 25-pin male connector of the
Z3A2 ADU.
!
CAUTION:
If the printer is in a building outside the main building (control unit
location), you must install an ADU and an additional protector in each
building. The ADUs and protectors provide both the control unit and the
printer with additional protection against lightning, inadvertent contact
with power lines, and power currents induced by nearby power lines.
See the installation notes packaged with the ADU for more information.
5 Plug one end of a D8W cord into the WALL jack on the Z3A2 ADU.
6 Plug the other end of the D8W cord into an ADU crossover cable.
7 Plug the other end of the ADU crossover cable into one of the jacks on a
400B2 power adapter.
8 Plug one end of a D6AP cord into the other jack of the 400B2 adapter.
