Installing Adjuncts

c Plug the power supply into a 117-V AC outlet that is not controlled by a
wall switch.
d Insert the plug end of the 400B or 400B2 adapter into the wall jack.
13 Test the MFM for T/R operation.
See "Testing MLX Telephones with MFMs" in Chapter 7.
14 Attach the adjunct to the MFM. See "Installing Adjuncts."
Installing Adjuncts
This section provides general instructions for connecting most adjuncts.
NOTE:
If you need to connect the adjuncts differently from the instructions on the
system forms, record each jack and adjunct change on the appropriate
system numbering form. See Appendix A, "System Numbering Forms."
1 Connect one end of the cord packaged with the adjunct (usually a D4BU
cord) to the adjunct.
See the documentation packaged with the adjunct for instructions.
2 Check the system form for the adjunct you want to connect. Then refer to
the appropriate step below.
To connect an adjunct to an MLX telephone, go to Step 3.
To connect an adjunct to a single-line telephone, go to Step 4.
To connect an adjunct to an analog multiline telephone, go to Step 5.
To connect an adjunct to a 012 0r 016 module, go to Step 6.
When you connect adjuncts to telephones, make sure you route the adjunct
and D8W telephone cords through the cord channel. See Figure 3–20.
3 Insert the other end of the adjunct cord into the TEL/OTHER jack on the
back of the MLX telephone. Go to Step 7.
