Connecting a PC to the Control Unit
Connecting a PC More Than
50 Feet (15.2 m) Away
Use this procedure to connect a PC to the control unit when the distance is 50 ft.
(15.2 m) or more.
NOTE:
If you are installing the PC in a different room than the control unit, make sure
that both locations have working wall outlets and wall jacks. Also make sure
that the building wiring has been connected so that the wall jacks in each
location connect to each other.
You need the following hardware for this procedure:
355AF adapter
EIA crossover cable
Two Z3A2 Asynchronous Data Units (ADUs)
ADU crossover cable
400B2 power adapter
2012D transformer
BR1A-4P adapter and 102 connecting block or 103 connecting block
248B adapter
8-position wall jacks
4-pair plug-ended cable
D8W cords
D6AP power cord
EIA-232-D cables
