Video Conferencing Data Stations
7 If it is not already connected, connect the CSU to the 100D module on the
control unit and to the 5ESS or 4ESS exchange switch.
See "Installing the Channel Service Unit" in Chapter 4.
8 When you are ready to power up the system, plug the power supplies,
CSU, video conferencing equipment, and control unit into the AC outlets.
Terminal Adapter and CSU Settings
You need to set the terminal adapter and the CSU as indicated in Table 6–2. If
the customer's system is running at 56 kbps, set the CSU line-coding DIP
switches according to the instructions in "Setting the CSU DIP Switches" in
Chapter 4.
Table 6–2. Terminal Adapter Settings
Settings
Auto-dial
Busy out
Datarest
DTR
Duplex
Mode
Speed
56 Kbps 64 Kbps
Off Off
Off Off
On Off
Follow Follow
Full Full
Cs Cs
56,000 64,000
Connecting Data Equipment
6–21
