Upgrading the Control Unit
2
Figure 9–4. Replacing a Module in the Carrier
3 Remove the clips from the left side of the control unit as you did in
Step 1; however, make sure you replace the clips before securing the
screws again.
4 Reinstall the power supply module by hooking it onto the rod at the top
of the carrier and then swinging it down into place. See Figure 9–4.
5 Push the power supply module firmly until you hear it lock.
1
3
Upgrading the System
9–11
