Overview
— Basic carrier and two expansion carriers: 37 in. wide by 23 in. high
by 12 in. deep
Location
— Within 5 ft. (152 cm) of an AC power outlet that is not switch-
controlled
— Within 25 ft. (762 cm) of the network interface, or use an Off-
Premises Range Extender (OPRE)
— Within 1000 cable ft. (305 m) of telephones, or use an OPRE (for
basic telephones)
!
CAUTION:
The AC outlet for the control unit cannot be switch-controlled. Plugging
the control unit into such an outlet invites accidental disconnection of
the system.
Hardware Preassembly Process
If an installation is to be preassembled, wired, programmed, and tested on
the new lightweight plastic backboard, see "Installing the Backboard."
Backboard Requirements
The backboard should be wide enough to accommodate the carrier and up to
two additional carriers, assuming that system growth is anticipated. There
should be enough room on each side of the control unit for the necessary
wiring fields.
To accommodate the maximum control unit size, make sure the backboard
meets the following requirements:
Material
— ¾-inch plywood
— Check with the local building code enforcement agency to see
whether fire-retardant material is required.
2–4
Installing the Control Unit
