AT&T MERLIN LEGEND Release 3.1 Installation Manual page 122

Installing Direct Station Selectors
To connect a DSS, follow the steps below. If you are connecting two DSSs to
the telephone, unpack the second DSS before you start.
1 Adjust the angle of the DSS.
The DSS is packed fully assembled with the deskstand in the low
position. If you prefer the low position, go to Step 2.
To adjust the angle of the DSS to the high position:
a Place the DSS face down on a flat surface.
b Press on the top rear center of the stand to release the tab, then
pull the stand toward you and away from the DSS.
c Insert the tab at the bottom of the stand into the other slot.
d Lower the stand and press the tab at the top into the corresponding
slot on the DSS.
2 Install the D8AC cord on the DSS.
a Plug one end of the D8AC cord into the IN jack on the DSS.
b Route the D8AC cord through the cord channel on the left side of the DSS.
c If you are installing only one DSS, go to Step 4.
If you are installing two DSSs, repeat Steps 1 and 2 for the second DSS,
then go to Step 3.
3 Wire the two DSSs. See Figure 3–28.
a Place the two DSSs side by side and face down.
b Route the D8AC cord from the IN jack on the second DSS (DSS2) through
the cord channel on the first DSS (DSS1).
c Plug this D8AC cord into the OUT jack on DSS1.
3–44
Installing Telephones and Adjuncts
