Data Stations
Table 6–1. Data Station Configurations
Type of Telephone
Station (for voice)
Analog voice Analog multiline
and modem telephone and
data BR-241-B1
bridging adapter
Modem None
data-only*
MLX voice and Any MLX
modem data telephone
MLX voice and Any MLX
Terminal telephone
Adapter
Terminal None
Adapter
data-only
Synchronous Passive bus MLX None
Terminal
Adapter for
Video MLX 2B
Data
* A single-line telephone may be attached for dialing purposes.
6–2
Connecting Data Equipment
GPA or
MFM DCE
GPA Modem
None Modem
MFM Modem
None 7500B or
ExpressRoute
Terminal
Adapter
None 7500B or
ExpressRoute
Terminal
Adapter and
a 440A4
terminating
resistor
adapter
PE equipment
or Terminal
Adapter
DTE
Terminal, PC, fax (cannot
dial), optical scanner, or
host computer
Terminal, PC, fax, credit
card verification, optical
scanner, or host computer
Terminal, PC, fax, credit
card verification, optical
scanner, or host computer
Terminal, PC, fax, credit
card verification, optical
scanner, host computer,
or video codec
Terminal, PC, fax, credit
card verification, optical
scanner, host computer,
or video codec
A PC with video
applications
