MERLIN PFC

Modem cable with a 9-pin connector at one end and a 25-pin
connector at the other end to connect the remote maintenance device
to the serial port on the MERLIN MAIL Voice Messaging System unit
D4BU modular cords (two for a 2-port system or four for a 4-port
system, plus one for the remote maintenance device)
012 or 016 basic telephone module
For more information, consult MERLIN MAIL Voice Messaging System for the
MERLIN LEGEND Communications System, Installation, System
Programming, and Maintenance.
MERLIN PFC
The MERLIN PFC (Phone-Fax-Copier) telephone is a 34-button display
telephone with a built-in fax and personal copier that provides the
convenience of a fax machine and personal copier in one compact unit. The
MERLIN PFC allows the user to make and receive inside and outside calls
using the built-in speakerphone, and to send and receive faxes or make quick
copies while using the telephone.
Considerations
The fax machine component of the MERLIN PFC telephone does not transmit
date, time, and fax number.
In Behind Switch mode, a dedicated fax line for incoming fax calls is also
required; in Hybrid/PBX or Key mode, the system can have either a dedicated
fax line or Direct Inward Dialing (DID).
You cannot install the MERLIN PFC telephone outside a building.
You must remove all button assignments except the one for the fax line from
the fax extension.
Installing Applications
8–21
