Connecting a Printer to the Control Unit
Table 5–3. AT&T CAT Printer DIP Switch Settings*
Switch 1 Switch 2
DIP 1-On DIP 1-On
DIP 2-On DIP 2-On
DIP 3-On DIP 3-Off
DIP 4-On DIP 4-Off
DIP 5-On DIP 5-On
DIP 6-On DIP 6-On
DIP 7-On DIP 7-On
DIP 8-On DIP 8-Off
* Open = off; Closed = on
Applications Printer DIP Switch Settings
For the Applications Printer, the only DIP switch setting is the control switch.
Set all control switch DIP switches (1 through 8) to Off (open).
Control Switch
DIP 1-Off
DIP 2-Off
DIP 3-Off
DIP 4-Off
DIP 5-On
DIP 6-Off
DIP 7-On
DIP 8-Off
Installing the PC, CAT, or Printer
5–25
