CHAPTER 6 USING CompoBus/D (DEVICENET)
J Communication
error status
J Status A
J Status B
6--12
• Check whether or not channel data is being read or written correctly
by "status at read" or "status at write", respectively.
• The following shows the check bits of each channel. These bit assign-
ments are the same for both "status at read" or "status at write".
15 14 13 12 11
CH CH CH CH CH
16 15 14 13 12
• "0" indicates a normal channel, and "1" indicates a channel in error.
For example, if channels 5 (CH5) and 3 (CH3) are in error, bits 4 and
2 become "1". Data is expressed as "0014" (Hex).
• Check the internal status of E5EK-DRT by "status A" or "status B."
• The following table shows the meanings of "status A" bits:
Bit Description
0 Heating side output
1 Cooling side output
2 Alarm output 1
3 Alarm output 2
4 Alarm output 3
5 LBA output
6 HBA output
7 Run/Stop
8 Auto/Manual
9 Remote/Local
10 SP mode
11 Auto-tuning
12
13
14
15
*1 Always "OFF" at linear output
*2 Always "OFF" when output is not assigned
• The following table shows the meanings of "status B" bits:
Bit Description
0
1 RAM write mode
2 Control output 1 type
3 Control output 2 type
4 EEPROM
5 Input error
6 A/D converter error
7 CT overflow
8 CT hold
9
10 RSP input error
11
12
13
14
15
10 9 8 7 6 5
CH CH CH CH CH CH CH
11 10 9 8 7 6
"1"
ON
ON
ON
ON
ON
ON
ON
Run
Manual
Remote
RSP
AT execution
"1"
Backup
Linear
Linear
RAM≠EEPROM
ON
ON
ON
ON
ON
4 3 2 1 0
CH CH CH CH
5 4 3 2 1
"0"
OFF *1
OFF *1
OFF *2
OFF *2
OFF *2
OFF *2
OFF *2
Stop
Auto
Local
LSP
OFF
"0"
RAM
Pulse
Pulse
RAM=EEPROM
OFF
OFF
OFF
OFF
OFF
