Table Data Processing Instructions
Operands
Operand Specifications
C and C+1: Control words
C specifies the number of words in the range, bit 15 of C+1 indicates whether
the data will be treated as signed binary or unsigned binary, and bit 14 of C+1
indicates whether or not to output the PLC memory address of the word that
contains the maximum value to IR0.
15
C
Number of words in range
15 14 13
00 0000
C+1
Output selection
0: Does not output address to IR00.
1: Outputs address to IR00.
Data type
0: Unsigned binary data
1: Signed binary data
The following table shows the possible values of C.
C+1 Data type
0000 Unsigned binary
4000 Unsigned binary
8000 Signed binary
C000 Signed binary
R1: First word in range
R1 specifies the first word in the search range. The words from R1 to R1+(C–
1) are searched for the maximum value. (C is the number of words specified in
C.)
15
Search range
R1
to ---
R1+(C–1)
Area
CIO Area CIO 0 to CIO 6142
Work Area W0 to W510
Holding Bit Area H0 to H510
Auxiliary Bit Area A0 to A958
Timer Area T0000 to T4094
Counter Area C0000 to C4094
DM Area D0 to D32766
Indirect DM @ D0 to @ D32767
addresses in binary
Indirect DM *D0 to *D32767
addresses in BCD
Constants Specified values only ---
0
0
0000 0000
0
Index Register output
No
Yes
No
Yes
0
C
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959
T0000 to T4095
C0000 to C4095
D0 to D32767
Section 3-16
R1 D
