Special Math Instructions
464
In this case, the source word, CIO 1000, contains 0014, and f(0014) = 0726 is
output to R, CIO 1001.
Y
$1F20
$0F00
$0726
$0402
(0,0)
$0005
The linear-extrapolation calculation is shown below.
0402 0F00 –
-------------------------------- -
Y = 0F00 +
001A 0005 –
= 0F00 – 0086 000F
= 0726
Values are all hexadecimal (hex).
(x,y)
$0014 $001A
0014 0015 –
Section 3-13
X
$05F0
