Floating-point Math Instructions
Precautions
3-14-14 ARC SINE: ASIN(463)
Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
500
Name Label
Underflow Flag UF
Negative Flag N
The source data in S+1 and S must be in IEEE754 floating-point data format.
Calculates the arc sine of a 32-bit floating-point number and places the result
in the specified result words. (The arc sine function is the inverse of the sine
function; it returns the angle that produces a given sine value between –1 and
1.)
ASIN(463)
S
R
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
OK OK
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Indirect DM addresses
in binary
Indirect DM addresses
in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
Operation
OFF
ON if the result is negative.
OFF in all other cases.
S: First source word
R: First result word
Step program areas Subroutines
OK
S
CIO 0 to CIO 6142
W0 to W510
H0 to H510
A0 to A958
T0000 to T4094
C0000 to C4094
D0 to D32766
@ D0 to @ D32767
*D0 to *D32767
#00000000 to #FFFFFFFF
(binary)
---
---
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Section 3-14
ASIN(463)
@ASIN(463)
Not supported.
Interrupt tasks
OK
R
A448 to A958
---
