Sequence Control Instructions
3-4-6 JUMP and JUMP END: JMP(004) and JME(005)
Purpose
Ladder Symbols
Variations
Applicable Program Areas
Operands
Operand Specifications
154
When the execution condition for JMP(004) is OFF, program execution jumps
directly to the first JME(005) in the program with the same jump number.
JMP(004) and JME(005) are used in pairs.
JMP(004)
N
JME(005)
N
Variations Jumps when OFF/Does Not Jump when ON
Immediate Refreshing Specification
Variations Executed Each Cycle for ON Condition
Immediate Refreshing Specification
Block program areas
OK Not allowed
N: Jump Number
The jump number must be 0000 to 00FF (&0 to &255 decimal).
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Indirect DM addresses in
binary
Indirect DM addresses in
BCD
Constants
Data Registers
Index Registers
Indirect addressing using
Index Registers
N: Jump number
N: Jump number
Step program areas Subroutines
OK
JMP(004)
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959
T0000 to T4095
C0000 to C4095
D0 to D32767
@ D0 to @ D32767
*D0 to *D32767
#0000 to #00FF (binary) or
&0 to &255
DR0 to DR15
---
,IR0 to ,IR15
–2048 to +2047, IR0 to
–2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
Section 3-4
JMP(004)
Not supported
JME(005)
Not supported
Interrupt tasks
OK
N
JME(005)
---
---
---
---
---
---
---
---
---
#0000 to #00FF (binary) or
&0 to &255
---
---
---
