5. Write to TCISTCMPL, TCISTCMPM, TCISTMSKL, and TCISTMSKM if needed to initiate an interrupt,
based on STC absolute time.
6. Write to TCITICKS if an interrupt is desired every x cycles of STC.
7. Write to VPCTL to select TCI capture operation (TCI = 1).
8. Write to VPIE to enable overrun (COVRA) and capture complete (CCMPA) interrupts, if desired.
9. Write to VCACTL to set capture mode (CMODE = 010).
10. Set VCEN bit in VCACTL to enable capture.
11. Capture begins on the first VCLKINA rising edge when CAPENA and PACSTRT are valid. A EDMA
event is generated as triggered by VCATHRLD1. When the entire packet has been captured
(DCOUNT = VCYSTOP and VCXSTOP combined value), the FRMC bit in VCASTAT is set causing the
CCMPx bit in VPIS to be set. This generates a DSP interrupt, if CCMPx is enabled in VPIE.
12. If continuous capture is enabled, the video port begins capturing again on the next VCLKIN rising
edge when CAPEN and PACSTRT are valid. If noncontinuous capture is enabled, the next data packet
is captured during which the DSP must clear the FRMC bit or further capture is disabled. If single
frame capture is enabled, capture is disabled until the DSP clears the FRMC bit.

3.12.1 Handling FIFO Overrun Condition in TCI Capture Mode

In case of a FIFO overrun, the COVRx bit is set in VPIS. This condition initiates an interrupt to the DSP, if
the overrun interrupt is enabled (setting the COVRx bit in VPIE enables overrun interrupt).
The overrun interrupt routine should set the BLKCAP bit in VCxCTL and it should reconfigure EDMA
channel settings. The EDMA channel must be reconfigured for capture of the next frame since the current
frame transfer failed. Setting the BLKCAP bit flushes the capture FIFO and blocks EDMA events for the
channel. As long as the BLKCAP bit is set, the video capture channel ignores the incoming data but the
internal data counter continues counting.
The BLKCAP bit should be cleared to 0 in order to continue capture. Clearing the BLKCAP bit takes effect
on the next PACSTRT. (EDMA events are still going to be blocked in the TCI packet in which the BLKCAP
bit is cleared.)

3.13 Video Capture Registers

The registers for controlling the video capture mode of operation are listed in
device-specific datasheet for the memory address of these registers.
Offset
(1)
Address Acronym
100h VCASTAT
104h VCACTL
108h VCASTRT1
10Ch VCASTOP1
110h VCASTRT2
114h VCASTOP2
118h VCAVINT
11Ch VCATHRLD
120h VCAEVTCT
140h VCBSTAT
144h VCBCTL
148h VCBSTRT1
14Ch VCBSTOP1
150h VCBSTRT2
(1)
The absolute address of the registers is device/port specific and is equal to the base address + offset address. See the
device-specific datasheet to verify the register addresses.
70 Video Capture Port
Table 3-13. Video Capture Control Registers
Register Name
Video Capture Channel A Status Register
Video Capture Channel A Control Register
Video Capture Channel A Field 1 Start Register
Video Capture Channel A Field 1 Stop Register
Video Capture Channel A Field 2 Start Register
Video Capture Channel A Field 2 Stop Register
Video Capture Channel A Vertical Interrupt Register
Video Capture Channel A Threshold Register
Video Capture Channel A Event Count Register
Video Capture Channel B Status Register
Video Capture Channel B Control Register
Video Capture Channel B Field 1 Start Register
Video Capture Channel B Field 1 Stop Register
Video Capture Channel B Field 2 Start Register
www.ti.com
Table 3-13. See the
Section
Section 3.13.1
Section 3.13.2
Section 3.13.3
Section 3.13.4
Section 3.13.5
Section 3.13.6
Section 3.13.7
Section 3.13.8
Section 3.13.9
Section 3.13.1
Section 3.13.10
Section 3.13.3
Section 3.13.4
Section 3.13.5
SPRUEM1 – May 2007
Submit Documentation Feedback
