Figure 11-3 Removing a power supply unit
2. Support the power supply unit with one hand from below and carefully pull it
out of the slot.
Note - Place the removed power supply unit on the grounded ESD mat to ground any static
electricity.
11.4

Installing a Power Supply Unit

This section describes the procedure for installing a power supply unit.
11.4.1 Installing a power supply unit
This section describes the procedure for installing a power supply unit.
Support the power supply unit from below with one hand and insert it
1.
carefully into its slot.
148 Fujitsu M10-1/SPARC M10-1 Service Manual ･ June 2021
B
A
