Page 3: Table Of Contents
Types of Bundles Overview ..........3 Interface Naming Conventions for the CTP Series ......4 Serial Multiservice Interface Module Overview .
Page 9: Overview Of Ctp Bundles
CHAPTER 1 Overview of CTP Bundles Types of Bundles Overview on page 3 Interface Naming Conventions for the CTP Series on page 4 Serial Multiservice Interface Module Overview on page 5 Adaptive Clocking Overview for CTP Bundles on page 7...
Page 10: Interface Naming Conventions For The Ctp Series
T1/E1 interface 4W-E&M interface Voice compression module FXS interface FXO interface Interface Naming Conventions for the CTP Series In the CTP software, interfaces are specified in the format: type-slot/port where type—Type of interface. A two-character abbreviation. slot—Slot number on the CTP device.
Page 11: Serial Multiservice Interface Module Overview
Audio mode provides a high-quality audio (CD quality) interface. Audio mode supports the following features: One or two simultaneous channels. Codec sampling rates up to 48 KHz. Optional μ-law encoding and decoding. Embedded frame requiring no additional bandwidth. Copyright © 2018, Juniper Networks, Inc.
Page 12: 4Wto Mode
GPS receiver status. IRIG-B encodes day of year, hour, minute, and second data on a 1-KHz carrier frequency, with an update rate of once per second. Copyright © 2018, Juniper Networks, Inc.
Page 13: Tdc Mode
This process is called adaptive time domain processing (ATDP). ATDP provides rapid convergence to the correct clock, and does not vary due to changes in the average jitter buffer fill. As a result, Copyright © 2018, Juniper Networks, Inc.
Page 14: Determining Optimal Packet Size For Ctp Bundles Overview
Bandwidth for Transporting Serial Data When considering bandwidth in relation to deciding packet size, add overhead for both the Layer 2 encapsulation and the IP header. The IP header comprises 20 bytes; and the Copyright © 2018, Juniper Networks, Inc.
Page 15: Packet Creation Delay
For example, smaller packets result in a greater packet rate. When you configure the packet size, consider the packet-forwarding performance of the attached router and network. Table 4 on page 10 provides examples of packet rates for various packet sizes and serial interface rates. Copyright © 2018, Juniper Networks, Inc.
Page 16: Providing Qos For Ctp Bundles By Using Service Type Overview
The EF class (ToS setting 184) is commonly used for circuit traffic. Table 5: DSCP Classes and Service Type DSCP Class DSCP Setting ToS Setting Copyright © 2018, Juniper Networks, Inc.
Page 17: Circuit Startup Process Overview
Configuring IP Parameters for CTP Bundles (CTP Menu) on page 27 Circuit Startup Process Overview CTP devices use UDP operational and maintenance (OAM) packets to initially discover the circuit on the remote CTP device, and to verify continued connectivity with the remote Copyright © 2018, Juniper Networks, Inc.
Page 18: Transparent Encoding Overview
Clocks must disappear (transitions stop) periodically during circuit operation. The transparent encoding scheme is supported only when you have worked with the Juniper Networks Technical Assistance Center (JTAC) to verify that your application requires this encoding scheme. You may need to use special adapters on the cable to properly map the data and clock signals to the connector pins that the application uses.
Page 19: How Basic Transparent Encoding Works
This allows signals to be sent from additional interfaces that were not supported in Transparent 4 encoding, although the bandwidth usage will be higher. Copyright © 2018, Juniper Networks, Inc.
Page 20: Using Phase-Correction Fifo Buffer With Transparent Encoding
The data enters the FIFO buffer in phase with the clock passing through the network from the DTE to the DCE, while data is clocked out of the FIFO buffer with the clock that entered the network from the DCE, which is in phase with the user clock. Copyright © 2018, Juniper Networks, Inc.
Page 21 Using Send Timing (ST) Clocking for Higher Speed Circuits with Transparent Encoding on page 16 Configuring Transparent Encoding for CTP Bundles (CTP Menu) on page 60 Configuring Transparent Encoding for CTP Bundles (CTPView) on page 58 Copyright © 2018, Juniper Networks, Inc.
Page 22: Encoding
ST functionality: At the DCE, the RTS-to-CTS signal path is configured to use ST (as an input from the DCE) to feed that signal path through the network. Copyright © 2018, Juniper Networks, Inc.
Page 23: Tdm/Tdc Encoding Overview
When TDM is not being used, all 32 bits in the IP data stream transport serial data on a port. For example, Figure 8 on page 18 shows all 32 bits being allocated to local serial port data as indicated with the D. Copyright © 2018, Juniper Networks, Inc.
Page 24: How The Ctp Implementation Of Tdm/Tdc Works
RT and RD outputs. The direct interleaving of two bundles’ data allows TDC to be maintained between the two bundles with an accuracy of one bit time at the bundle’s data rate. Copyright © 2018, Juniper Networks, Inc.
Page 25: Tdm Rates
If the ratio of circuit speeds is higher than 8:1, then you can use lower TDM rates, which allocates fewer bits for the TDM function and therefore uses less network bandwidth. Figure 13 on page 20 shows other supported TDM rates as applied to TDC. Copyright © 2018, Juniper Networks, Inc.
Page 26: Tdm High-Speed And Low-Speed Ports
The low-speed bundle is configured on an odd-numbered port that is one port number higher (N+1) than the high-speed port. It is configured for TDM/TDC clocking because it routes clock and data signals. Figure 14 on page 21 shows a high-speed port and low-speed port. Copyright © 2018, Juniper Networks, Inc.
Page 27 TDM/TDC bundle to the user equipment. Related Configuring Bundle Pairs for TDM/TDC Operation (CTP Menu) on page 64 Documentation Configuring Bundle Pairs for TDM/TDC Operation (CTPView) on page 62 Copyright © 2018, Juniper Networks, Inc.
Page 29: Configuring Ctp Bundles
Configuring Bundle Pairs for TDM/TDC Operation (CTP Menu) on page 64 Configuring T1 and E1 Port Parameters for CTP Bundles (CTPView) on page 66 Configuring T1 and E1 Port Parameters for CTP Bundles (CTP Menu) on page 69 Copyright © 2018, Juniper Networks, Inc.
Page 30: Adding A Bundle (Ctpview)
Connect the CTPView server to the CTP device for which you want to configure bundles. To add a bundle using CTPView: In the side pane, select Bundle > Configuration. Run your mouse over the Open Add Bundles Display bar. Copyright © 2018, Juniper Networks, Inc.
Page 31: Adding A Bundle (Ctp Menu)
Select the port you want to attach the bundle to. Configuring IP Parameters for CTP Bundles (CTPView) The CTP software uses the IP parameters to create IP packets. Before you begin: Log in to the CTPView software at least at the Net_Admin level. Copyright © 2018, Juniper Networks, Inc.
Page 32 The minimum buffer ensures that the buffer does not become too small because of timing variances between the local and remote serial interfaces. The entire buffer is available for accommodating and smoothing packet delay jitter, regardless of the minimum buffer setting. Copyright © 2018, Juniper Networks, Inc.
Page 33: Configuring Ip Parameters For Ctp Bundles (Ctp Menu)
Disable the bundle before you modify the bundle options. To configure IP parameters for CTP bundles using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. Copyright © 2018, Juniper Networks, Inc.
Page 34 Pkt Buffer Set value. Periodic buffer recenters are not expected. If you notice recenters, we recommend that you verify the reference to the CTP (if used) or that you configure one port with adaptive clocking. Copyright © 2018, Juniper Networks, Inc.
Page 35: Configuring Circuit Startup Parameters For Ctp Bundles (Ctpview)
In the table of bundles, select the bundle that you want to modify. Under Bundle Options, select Advanced Options Show to display advanced parameters and configure the parameters as described in Table 8 on page Click Click to Submit Bundle AND Port Changes. Copyright © 2018, Juniper Networks, Inc.
Page 36: Configuring Circuit Startup Parameters For Ctp Bundles (Ctp Menu)
From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 2) Config. Copyright © 2018, Juniper Networks, Inc.
Page 37: Configuring The Ctp Bundle Data Packet Protocol And Oam Port
*** a system reboot when complete. *** If you decide to continue, the system will automatically *** reboot upon leaving these menus. *** Note: If these parameters are changed incorrectly, system may not be reachable via the network Copyright © 2018, Juniper Networks, Inc.
Page 38: Ethernet Media Configuration Overview
You must disable Cisco Discovery Protocol on the Fast Ethernet port connected to the CTP system. Table 10 on page 32 lists the valid Ethernet media configuration settings that CTP Series supports. Table 10: Valid Ethernet Media Configuration Settings for CTP...
Page 39: Devices
(NIC) ports are acquired, regardless of the duplex setting configured on the far-end node. After the autonegotiation process is completed, if the CTP NIC cannot acquire full-duplex mode, then the interfaces are considered to be down and a log message is Copyright © 2018, Juniper Networks, Inc.
Page 40: Configuring Ethernet Media (Ctp Menu)
Autonegotiation is enabled by default and the speed is set to 1000 Mbps Field Function Your Action Please input the device to Specifies the Ethernet port Specify an Ethernet port from the list. configure the media for Copyright © 2018, Juniper Networks, Inc.
Page 41: Configuring The Direction Of The Circuit (Ctpview)
Connect the CTPView server to the CTP device for which you want to configure bundles. To configure the direction of circuits created with the CTP bundle using CTPView: In the side pane, select Bundle > Configuration. Run your mouse over the Display and Select an Existing Bundle bar. Copyright © 2018, Juniper Networks, Inc.
Page 42: Configuring The Direction Of The Circuit (Ctp Menu)
Select a bundle from the list. If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 2) Config. Select 10) Advanced Options. Configure option 10 as described in Table 12 on page Copyright © 2018, Juniper Networks, Inc.
Page 43: Configuring Virtual Ip Parameters For Ctp Bundles (Ctpview)
In the table of bundles, select the bundle that you want to modify. Under Bundle Options, select Advanced Options Show to display advanced parameters and configure the parameters as described in Table 13 on page Click Click to Submit Bundle AND Port Changes. Copyright © 2018, Juniper Networks, Inc.
Page 44: Configuring Virtual Ip Parameters For Ctp Bundles (Ctp Menu)
If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 2) Config. Select 10) Advanced Options. Configure options 1 and 2 as described in Table 14 on page Copyright © 2018, Juniper Networks, Inc.
Page 45: Configuring The Missing Packet Fill Pattern For Ctp Bundles (Ctpview)
When the bundle is down, the port sends the value of the least significant bit (LSB) of the missing fill pattern. This data insertion method prevents a loss of bit count integrity to attached circuit devices and encryptors. Copyright © 2018, Juniper Networks, Inc.
Page 46: Configuring The Missing Packet Fill Pattern For Ctp Bundles (Ctp Menu)
When the bundle is down, the port sends the value of the least significant bit (LSB) of the missing fill pattern. This data insertion method prevents a loss of bit count integrity to attached circuit devices and encryptors. Copyright © 2018, Juniper Networks, Inc.
Page 47: Configuring Ip Forwarding For Ctp Bundles (Ctpview)
In the table of bundles, select the bundle that you want to modify. Under Bundle Options, select Advanced Options Show to display advanced parameters and configure the parameters as described in Table 17 on page Click Click to Submit Bundle AND Port Changes. Copyright © 2018, Juniper Networks, Inc.
Page 48: Configuring Ip Forwarding For Ctp Bundles (Ctp Menu)
Disable the bundle before you modify the bundle options. To configure IP forwarding for CTP bundles using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. Copyright © 2018, Juniper Networks, Inc.
Page 49 When direct drive is disabled, packets are forwarded based on information in the kernel’s IP stack. When direct drive is enabled, packets are forwarded directly between drivers on the local and remote CTP device. Copyright © 2018, Juniper Networks, Inc.
Page 50: Configuring Signaling For Ctp Bundles (Ctpview)
Before you begin: Log in to the CTPView software at least at the Net_Admin level. Connect the CTPView server to the CTP device for which you want to configure bundles. Copyright © 2018, Juniper Networks, Inc.
Page 51 DTR input signal from the DCE or the DSR signal from the DTE. InBand - From Remote LL—Output signal is based on the state of the LL input signal from the DCE or the DCD signal from the DTE. Copyright © 2018, Juniper Networks, Inc.
Page 52 DTR input signal from the DCE or the DSR signal from the DTE. InBand - From Remote LL—Output signal is based on the state of the LL input signal from the DCE or the DCD signal from the DTE. Copyright © 2018, Juniper Networks, Inc.
Page 53 Unused—Input signals are ignored. DCE or the DTE: Demand Call - Active High—Signal is turned off. DCE—LL input signal. Demand Call - Active Low—Signal is turned on. DTE—DCD input signal. Copyright © 2018, Juniper Networks, Inc.
Page 54: Configuring Signaling For Ctp Bundles (Ctp Menu)
Before you begin: Disable the bundle before you modify the bundle options. To configure signaling for CTP bundles using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Copyright © 2018, Juniper Networks, Inc.
Page 55 DCE or the DSR signal from the DTE. 3) LL from rem DCE, DCD from rem DTE—Output signal is based on the state of the LL input signal from the DCE or the DCD signal from the DTE. Copyright © 2018, Juniper Networks, Inc.
Page 56 DCE or the DSR signal from the DTE. 3) LL from rem DCE, DCD from rem DTE—Output signal is based on the state of the LL input signal from the DCE or the DCD signal from the DTE. Copyright © 2018, Juniper Networks, Inc.
Page 57 0) Unused—Input signals are ignored. DCE—DTR input signal. 1) Demand call. DSR (input) DTE—DSR input signal. If you chose Demand call, select an input signal value: 0=Space=Low=On—Signal is turned on. 1=Mark=High=Off—Signal is turned off. Copyright © 2018, Juniper Networks, Inc.
Page 58: Configuring Serial Port Parameters For Ctp Bundles (Ctpview)
Table 21: CTP Bundle Serial Port Parameter Settings in CTPView Field Function Your Action Port Description Specifies a description for the port. Enter a description of up to 64 alphanumeric characters. Do not use the following characters: ( ; ' " ) ] Copyright © 2018, Juniper Networks, Inc.
Page 59 See “Configuring the High-Speed CTP Bundle for TDM/TDC Operation (CTPView)” on page TDM Rate This option is used only for TDM/TDC operation. See “Configuring the High-Speed CTP Bundle for TDM/TDC Operation (CTPView)” on page Copyright © 2018, Juniper Networks, Inc.
Page 60: Configuring Serial Port Parameters For Ctp Bundles (Ctp Menu)
Disable the bundle before you modify the bundle options. To configure serial port parameters for CTP bundles using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. Copyright © 2018, Juniper Networks, Inc.
Page 61 Specifies that the interface is connected Select one: to a data communication equipment DCE—The interface is connected to (DCE) device or to a data terminal a DCE device. equipment (DTE) device. DTE—The interface is connected to a DTE device. Copyright © 2018, Juniper Networks, Inc.
Page 62 For CDI circuits, the maximum port speed is limited to 4608 KBps. The port speed also varies depending on hardware: CTP2000 devices cannot have an aggregate port rate greater than 114.688 Mbps. Copyright © 2018, Juniper Networks, Inc.
Page 63 “Configuring the High-Speed CTP Bundle for TDM/TDC Operation (CTP Menu)” on page TDM rates This option is used for TDM/TDC operation. See “Configuring the High-Speed CTP Bundle for TDM/TDC Operation (CTP Menu)” on page Copyright © 2018, Juniper Networks, Inc.
Page 64: Configuring Transparent Encoding For Ctp Bundles (Ctpview)
Table 23: CTP Bundle Transparent Encoding Parameter Settings in CTPView Field Function Your Action Port Speed Specifies the sample rate for user data. Enter a number from 0.00100 through The port rate should be a multiple of the 12880.00000 KHz. user data rate. Copyright © 2018, Juniper Networks, Inc.
Page 65 Invert FIFO Write Clock Specifies whether or not to invert the Select one: FIFO buffer write clock. DISABLED ENABLED Invert FIFO Read Clock Specifies whether or not to invert the Select one: FIFO read clock. DISABLED ENABLED Copyright © 2018, Juniper Networks, Inc.
Page 66: Configuring Transparent Encoding For Ctp Bundles (Ctp Menu)
TRANS encoding. Before you begin: Disable the bundle before you modify the bundle options. To configure transparent encoding using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Copyright © 2018, Juniper Networks, Inc.
Page 67 Specifies whether or not to invert the FIFO write clock. Specify y (yes) or n (no). Invert FIFO Read clock? Specifies whether or not to invert the FIFO read clock. Specify y (yes) or n (no). Copyright © 2018, Juniper Networks, Inc.
Page 68: Configuring Bundle Pairs For Tdm/Tdc Operation (Ctpview)
Connect the CTPView server to the CTP device for which you want to configure bundles. To configure a high-speed CTP bundle for TDM/TDC operation using CTPView: In the side pane, select Bundle > Configuration. Run your mouse over the Display and Select an Existing Bundle bar. Copyright © 2018, Juniper Networks, Inc.
Page 69: Configuring The Low-Speed Ctp Bundle For Tdm/Tdc Operation
Before you begin: Log in to the CTPView software at least at the Net_Admin level. Connect the CTPView server to the CTP device for which you want to configure bundles. Copyright © 2018, Juniper Networks, Inc.
Page 70: Configuring Bundle Pairs For Tdm/Tdc Operation (Ctp Menu)
Select 1) CTP. Select a bundle from the list. You must configure the bundle on an even-numbered port. If you select an active bundle, you are prompted to disable the bundle before configuring it. Copyright © 2018, Juniper Networks, Inc.
Page 71 If the rate is too high, the low-speed circuit will still run, but will likely use more bandwidth than necessary. You may want to configure a higher rate to increase the TDM rate to reduce jitter on the low-speed clock and data signals. Copyright © 2018, Juniper Networks, Inc.
Page 72: Menu)
This topic describes how to configure port parameters for T1/E1 interfaces. Before you begin: Log in to the CTPView software at least at the Net_Admin level. Connect the CTPView server to the CTP device for which you want to configure bundles. Copyright © 2018, Juniper Networks, Inc.
Page 73 B8ZS Framing Mode For fractional T1, ESF is the only option supported. With ESF framing, the frame synchronization, data link, and CRC framing bits are passed across the IP network untouched. Copyright © 2018, Juniper Networks, Inc.
Page 74 CTP device uses the adaptive recovered clock. You typically use this configuration when the CTP device does not have a reference input and the PBX typically requires a clock from the distant PBX. Copyright © 2018, Juniper Networks, Inc.
Page 75: Configuring T1 And E1 Port Parameters For Ctp Bundles (Ctp Menu)
The options vary depending on whether the bundle is T1 or E1 and whether fractional T1 or E1 is configured. To configure clocking for the port, select 3) Clock Config and configure the Clock Config option as described in Table 28 on page Copyright © 2018, Juniper Networks, Inc.
Page 76 ( ; ' " ) ] Type Specifies the type of interface. Select one: Fractional T1 Fractional E1 Option (for T1) Specifies the T1 encoding method used Select one: on this bundle. B8ZS Copyright © 2018, Juniper Networks, Inc.
Page 77 (CSS) is used. The common channel carries data messages that convey signaling for the circuits between two devices. y (yes)—Channel associated signaling (CAS) is used. Each traffic channel has a dedicated signaling channel (channel 16). Copyright © 2018, Juniper Networks, Inc.
Page 78: Configuring Multiservice Port Parameters For Ctp Bundles (Ctpview)
Connect the CTPView server to the CTP device for which you want to configure bundles. To configure Multiservice audio mode port parameters using CTPView: In the side pane, select Bundle > Configuration. Run your mouse over the Display and Select an Existing Bundle bar. Copyright © 2018, Juniper Networks, Inc.
Page 79 16 bits. If you enable μ-law encoding, the 16-bit DISABLED (16 bit samples)—Generates samples are converted to 8 bits, consuming half of the 16-bit audio samples. bandwidth without significant audio degradation. ENABLED (8 bit samples)—Generates 8-bit audio samples. Copyright © 2018, Juniper Networks, Inc.
Page 80 In the table of bundles, select the bundle that you want to modify. Under Bundle Options, configure the parameters as described in Table 30 on page 75 and click Click to Submit Bundle AND Port Changes. Copyright © 2018, Juniper Networks, Inc.
Page 81 This option appears only if you set the direction of the port to Tx. Enter a number from 0.00 through Volts Level 7.85 volts peak-to-peak. Specifies the low output level, which is measured in peak-to-peak voltage. This setting is based on a 50-ohm termination. Copyright © 2018, Juniper Networks, Inc.
Page 82: Configuring Multiservice Tdc Mode Parameters For Ctp Bundles
Specifies the output level. Enter a number from 0 through 255. Note the following information about the values: 0—There is no output. 128—Unity gain, which means there is no attenuation or gain. 255—Gain is 2:1. Copyright © 2018, Juniper Networks, Inc.
Page 83: Configuring Multiservice 4Wto Mode Port Parameters For Ctp Bundles
4WTO Channel Specifies the channel or channels to Select one: enable. Channel 0—Enables only channel 0. Each CTP bundle can support either one Dual Channel—Enables both channel or two channels. 0 and channel 1. Copyright © 2018, Juniper Networks, Inc.
Page 84: Configuring Multiservice Port Parameters For Ctp Bundles (Ctp Menu)
Configuring Multiservice Port Parameters for CTP Bundles (CTP Menu) Configuring Multiservice Audio Mode Port Parameters for CTP Bundles (CTP Menu) on page 79 Configuring Multiservice IRIG-B Mode Port Parameters for CTP Bundles (CTP Menu) on page 81 Copyright © 2018, Juniper Networks, Inc.
Page 85: Menu)
Dual Channel Two channels are supported—channel Select one: 0 and channel 1. Disable—Channel 0 is the only active Enables or disables the use of both channel. channels. Enable—Both channel 0 and channel 1 are active. Copyright © 2018, Juniper Networks, Inc.
Page 86 Note the following information about the values: 0—There is no output. 128—Unity gain, which means there is no attenuation or gain. 255—Gain is 2:1. See Also Serial Multiservice Interface Module Overview on page 5 Copyright © 2018, Juniper Networks, Inc.
Page 87: (Ctp Menu)
Follow the onscreen instructions and configure the options as described in Table 34 on page Table 34: CTP Bundle Multiservice IRIG-B Port Parameter Settings in the CTP Menu Field Function Your Action Mode Specifies that the bundle will run in Select IRIG. IRIG-B mode. Copyright © 2018, Juniper Networks, Inc.
Page 88 16,000 bps. Although the IRIG information can be transported through the network at the minimum configured rate (1000 bps), a CTP bundle running at this rate is subject to high latency. Copyright © 2018, Juniper Networks, Inc.
Page 89 Select 3) Port Config. Select 2) Interface. Select 1) Typeand set the type to Optional Interface: MultiSvc. Follow the onscreen instructions and configure the options as described in Table 35 on page Copyright © 2018, Juniper Networks, Inc.
Page 90: (Ctp Menu)
Select a bundle from the list. The bundle port must have a 4WTO daughter card installed. If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 3) Port Config. Select 2) Interface. Copyright © 2018, Juniper Networks, Inc.
Page 91 Specifies the output level for channel 1. Enter a number from 0 through 255. Note the following information about the values: 0—There is no output. 128—Unity gain, which means there is no attenuation or gain. 255—Gain is 2:1. Copyright © 2018, Juniper Networks, Inc.
Page 92: Configuring 4Wto Port Parameters For Ctp Bundles (Ctpview)
Table 37: CTP Bundle 4WTO Port Parameter Settings in CTPView Field Function Your Action Port Description Specifies a description for the port. Enter a description of up to 64 alphanumeric characters. Do not use the following characters: ( ; ' " ) ] Copyright © 2018, Juniper Networks, Inc.
Page 93 25—Unity gain, which means there is no attenuation or gain. 255—Gain is 4:1 (signal is amplified 400% or 6 dB). Intermediate values are derived with linear interpolation. The actual gain depends on the impedance of the attached device. Copyright © 2018, Juniper Networks, Inc.
Page 94 Multiservice Interface module is 4WTO daughter card with Multiservice disabled. Interface modules, the port speed for the bundle is set as follows: 64 when only channel 0 is enabled. 128 when dual channel is enabled. Copyright © 2018, Juniper Networks, Inc.
Page 95: Configuring 4Wto Port Parameters For Ctp Bundles (Ctp Menu)
Disable the bundle before you modify the bundle options. To configure port parameters for 4WTO daughter cards for CTP bundles using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Copyright © 2018, Juniper Networks, Inc.
Page 96 25—Unity gain, which means there is no attenuation or gain. 255—Gain is 4:1 (signal is amplified 400% or 6 dB). Intermediate values are derived with linear interpolation. The actual gain depends on the impedance of the attached device. Copyright © 2018, Juniper Networks, Inc.
Page 97 The clock slave references. uses its period to determine when to sample data and how to transmit data across the link. Custom—The custom clocking configuration is used. Copyright © 2018, Juniper Networks, Inc.
Page 98: Configuring Irig-B Port Parameters For Ctp Bundles (Ctpview)
Enter a number from 1.000 through 25.500 KHz. The port speed must be a multiple of 100 Unless network bandwidth is at a premium, we do not bps. recommend that you change this value from the default of 16,000 bps. Copyright © 2018, Juniper Networks, Inc.
Page 99 Voice/IRIG-B Slave End—This end of the circuit receives the clock signal from the remote end. The clock slave uses its period to determine when to sample data and how to transmit data across the link. Copyright © 2018, Juniper Networks, Inc.
Page 100: Configuring Irig-B Port Parameters For Ctp Bundles (Ctp Menu)
The options vary depending on whether the bundle is T1 or E1 and whether fractional T1 or E1 is configured. To configure clocking for the port, select 3) Clock Config and configure the Clock Config option as described in Table 40 on page Copyright © 2018, Juniper Networks, Inc.
Page 101 25,500 bps. The port speed must be a multiple of 100 bps. Unless network bandwidth is at a premium, we do not recommend that you change this value from the default of 16 Kbps. Copyright © 2018, Juniper Networks, Inc.
Page 102: Configuring Advanced Port Options For Ctp Bundles (Ctpview)
Reclock to Align Clock Do not change this value without consulting JTAC. Select ENABLED or and Data DISABLED. Specifies whether or not to reclock RD with the RT clock to align the data and the clock. Copyright © 2018, Juniper Networks, Inc.
Page 103: Configuring Advanced Port Options For Ctp Bundles (Ctp Menu)
From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 3) Port Config. Copyright © 2018, Juniper Networks, Inc.
Page 104 IP network. Substitute DDS when TT gone Helps maintain the low-speed port on a Select y or n. TDM/TDC CTP serial circuit at up when the high-speed circuit goes down. Copyright © 2018, Juniper Networks, Inc.
Page 105: Configuring Port Mirroring For Ctp Bundles (Ctpview)
Click to select the remote IP address from the list. Select the Remove Tail check box to remove the port mirroring tail from the bundle. The check box will be visible only if port mirroring is configured. Copyright © 2018, Juniper Networks, Inc.
Page 106: Configuring Port Mirroring For Ctp Bundles (Ctp Menu)
Select one: Bidirectional circuit—Select to configure both source ad destination port mirroring. Unidirectional circuit source—Select to configure only source port mirroring. Unidirectional circuit destination—Select to configure only destination port mirroring. Select 12) Port mirror Config. Copyright © 2018, Juniper Networks, Inc.
Page 107 Enter remote cid Enter the remote circuit ID in the range 0-249. From the Operations Menu, select 4) Activate to activate the bundle. Related Configuring Port Mirroring for CTP Bundles (CTPView) on page 99 Documentation Copyright © 2018, Juniper Networks, Inc.
Page 108: Configuring Cryptographic Resynchronization (Crypto Resync)
0) Back to Previous Menu 1) Crypto resync wait time: 4 sec 2) Crypto resync pulse width: 1 sec 3) Crypto resync pulse period: 8 sec 4) Crypto resync DSR in-sync value: 1 (mark/high/off) Copyright © 2018, Juniper Networks, Inc.
Page 109: Gathering Node Debugging Information (Ctp Menu)
This topic describes how to enable gathering node debugging information on CTP devices. To enable gathering node debugging information using the CTP Menu: From the Main Menu, select 4) Node Diagnostics. Select 10) Node debug data gathering. Copyright © 2018, Juniper Networks, Inc.
Page 110: Selecting The Type Of Clocking On Serial Ports For Ctp Bundles (Ctpview)
Under Port Options, select a clocking type in the Clock Cfg field. Table 48 on page 105 describes the clocking types that are supported for each encoding type. Click Click to Submit Bundle AND Port Changes. Copyright © 2018, Juniper Networks, Inc.
Page 111 The clock slave uses its period to determine when to sample data and how to transmit data across the link. If you specify slave end, the adaptive clocking configuration appears. Custom—The custom clocking configuration is used. Copyright © 2018, Juniper Networks, Inc.
Page 112: Selecting The Type Of Clocking On Serial Ports For Ctp Bundles (Ctp Menu)
From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 3) Port Config. Select 3) Clock Config. Copyright © 2018, Juniper Networks, Inc.
Page 113 DTE, All Clocked by User Clk(RT)—The DCE equipment provides all clocks. The RT input clock is used to clock out the external transmit clock (TT) and the send data (SD) and to clock in the receive data (RD). Custom—The custom clocking configuration is used. Copyright © 2018, Juniper Networks, Inc.
Page 114 TRANS - Adaptive End—This end of the circuit uses adaptive clocking to receive the clock signal from the remote end. The clock slave uses its period to determine when to sample data and how to transmit data across the link. Custom—The custom clocking configuration is used. Copyright © 2018, Juniper Networks, Inc.
Page 115: Configuring Custom Clocking For Ctp Bundles (Ctpview)
Specifies a fixed frequency for the Direct Enter a number from 1 through 2,147,483,647 Hz. Digital Synthesizer (DDS). DDS Post Specifies the divider for the DDS. Enter a number from 0 through 4. Divider Copyright © 2018, Juniper Networks, Inc.
Page 116 DCE. DIV—Divider clock generator. ST—Send timing clock. The interface clock signal from the DCE to the DTE (CTP device). The ST clock is used only if the bundle is configured as the DTE. Copyright © 2018, Juniper Networks, Inc.
Page 117 TT—Transmit timing clock. The external transmit clock used to provide clocking from the CTP device to the user equipment. DIV—Divider clock generator. ST—Send timing clock. The interface clock signal from the user equipment to the CTP device. Copyright © 2018, Juniper Networks, Inc.
Page 118: Configuring Custom Clocking For Ctp Bundles (Ctp Menu)
If you select an active bundle, you are prompted to disable the bundle before configuring it. Select 3) Port Config. Select 3) Clock Config. Select 1) Port Clock Config. Select Custom. Configure the options as described in Table 51 on page 113. Copyright © 2018, Juniper Networks, Inc.
Page 119 TT (ext clk)—Transmit timing clock. The interface clock signal from the DTE to the DCE (CTP device). RT (ext clk)—Receive timing clock. Interface clock signal from the DCE to the DTE (CTP device). DIV (synth)—Divider clock generator. Copyright © 2018, Juniper Networks, Inc.
Page 120 This parameter appears only if you have DDS (synth)—Direct digital synthesizer configured the bundle as the DCE. clock TT (ext clk)—Transmit timing clock. The interface clock signal from the DTE to the DCE (CTP device). DIV (synth)—Divider clock generator. Copyright © 2018, Juniper Networks, Inc.
Page 121: Configuring Adaptive Clocking For Ctp Bundles (Ctpview)
To configure adaptive clocking for CTP bundles using CTPView: In the side pane, select Bundle > Configuration. Run your mouse over the Display and Select an Existing Bundle bar. In the table of bundles, select the bundle that you want to modify. Copyright © 2018, Juniper Networks, Inc.
Page 122 Max Buffer Error Specifies the buffer error rate required Enter a number from 100 through to change the adaptive clocking 1,000,000 microseconds. algorithm state from maintenance to aggressive. Copyright © 2018, Juniper Networks, Inc.
Page 123: Configuring Adaptive Clocking For Ctp Bundles (Ctp Menu)
Enter a number from 3 through 200 start of adaptive clocking during which seconds. packet samples that are experiencing the least delay through the network are collected. These samples are used for aggressive state calculations. Copyright © 2018, Juniper Networks, Inc.
Page 124: Network Node Reference Overview
To operate in primary or backup mode, the remote primary node must be configured as a NetRef primary node with the IP address of the NetRef slave configured. The backup node must be Copyright © 2018, Juniper Networks, Inc.
Page 125: Guidelines For Configuring Netref
NetRef primary or master operation does not need a CTP bundle between the nodes. Related Configuring NetRef for Adaptive Bundle Operation on page 120 Documentation Configuring NetRef for Primary or Backup Operation on page 121 Copyright © 2018, Juniper Networks, Inc.
Page 126: Configuring Netref For Adaptive Bundle Operation
To use the bundle without the NetRef feature, you must first disable the bundle, turn off NetRef adaptive bundle operation, and then re-enable the bundle. Related Network Node Reference Overview on page 118 Documentation Configuring NetRef for Primary or Backup Operation on page 121 Copyright © 2018, Juniper Networks, Inc.
Page 127: Configuring Netref For Primary Or Backup Operation
To operate in primary or backup mode, the remote primary node must be configured as a NetRef primary node with the IP address of the NetRef slave configured. The backup node must be configured as a NetRef backup node with the IP address of the NetRef Copyright © 2018, Juniper Networks, Inc.
Page 128 The packets are processed by the slave nodes to synchronize their clock with the next highest priority master node. Flapping of the masters occurs if you continuously “round robin” to each master and wait for 20 seconds for an incoming NetRef packet. Copyright © 2018, Juniper Networks, Inc.
Page 129 “ 2 3 ; 1 ; 0 ; 0 ; 0 ; 0 ; 0 ; 0 ; 0 ; 0 ; 0 ; 5 ; 1 ; 5 ; 1 ; 5 ; 1 ; 5 ; 1 ; 5 ; 1 ; ; 2 | 6 4 | 1 0 . 2 1 6 . 1 1 8 . 7 3 /1 0 . 2 1 6 . 1 1 8 . 8 6 /1 0 . 2 1 6 . 1 1 8 . 9 0 /1 0 . 2 1 6 . 1 1 8 . 8 8 /1 2 7 . 0 . 0 . 1 /1 2 7 . 0 . 0 . 1 /1 2 7 . 0 . 0 . 1 /1 2 7 . 0 . 0 . 1 /1 2 7 . 0 . 0 . 1 / | 0 | 2 5 5 | ; 0 ; ” When node is configured as master, the node www_db string will remain same as it is there in the earlier releases. Copyright © 2018, Juniper Networks, Inc.
Page 130: Configuring Netref Multiple Master Nodes (Ctp Menu)
From the NetRef Menu, select 5) NetRef Master IP (Priority 1). and specify the IP address of the NetRef master node, which is assigned a priority of 4. Please select a number from the following list: ------------------------------------- 0) Exit to Shell Copyright © 2018, Juniper Networks, Inc.
Page 131 5) NetRef Master IP (Priority 4): 127.0.0.1 ------------ Your choice [2]: 2 Configure a NetRef Master? n[y]: y Enter remote node IP address for NetRef:(rtn for 127.0.0.1)? 10.216.118.73 ========================================================================== = (ctp_74 10/30/15 12:22:08 UTC) | NetRef Menu Copyright © 2018, Juniper Networks, Inc.
Page 132 Configure a NetRef Master? n[y]: y Enter remote node IP address for NetRef:(rtn for 127.0.0.1)? 10.216.118.88 ========================================================================== = (ctp_74 10/30/15 12:49:12 UTC) | NetRef Menu ========================================================================== Please select a number from the following list: ------------------------------------- Copyright © 2018, Juniper Networks, Inc.
Page 133 , and if you (rtn for 127.0.0.1) specify is set as the default IP address. 127.0.0.1 Related Configuring NetRef for Adaptive Bundle Operation on page 120 Documentation Network Node Reference Overview on page 118 Copyright © 2018, Juniper Networks, Inc.
Page 134: Configuring Netref Settings (Ctpview)
Master IP (Priority # Specifies the IP address of the master node with priority Enter the IP address of the master node with priority 1. Copyright © 2018, Juniper Networks, Inc.
Page 135: Loss Of Signal Detection Capability On Ctp Bundles And Satop Bundles
Starting with CTPOS Release 7.2R1, CTP devices support the detection of a loss of signal, which denotes a physical link problem. The following conditions are supported: Copyright © 2018, Juniper Networks, Inc.
Page 137: Detection Of Los On T1/E1 Interfaces
The following clock configurations use an external clock: DCE/DTE: Cfg Rate – Ext Clk DCE/DTE: All Clock – Ext Clk DCE/DTE: Adap Rate – Ext Clk DCE/DTE: Auto Rate – Ext Clk DTE: All clocked by Ext Clk (ST/RT) Copyright © 2018, Juniper Networks, Inc.
Page 138 CTP bundle or a SAToP bundle, and the NoRdReclk flag signifies that the redundancy receiving (RX) clock is disabled. The NoRdReclk flag is also displayed because this flag is default enabled for a T1/E1 port, whereas it is usually not enabled for a serial port. Copyright © 2018, Juniper Networks, Inc.
Page 139: Configuring Los Detection On Ctp And Satop Bundles (Ctp Menu)
Y cable link protocol), removal of Y cable leg from the CTP port of the online bundle must be able to force a switch to the standby bundle. A CTP series device provides two types of Y-cable redundancy. Redundancy by using a hardware link that uses a special Y cable...
Page 141: Administration
Configuring Diagnostic Testing for CTP Bundles on page 161 Displaying BERT Status and Counters for CTP Bundles on page 167 Reducing the Number of SNMP Traps Generated for Late and Missing Packets on page 171 Copyright © 2018, Juniper Networks, Inc.
Page 143: Activating, Disabling, Deleting, Or Recentering Ctp Bundles
Activating, Disabling, Deleting, or Recentering for CTP Bundles (CTP Menu) You can recenter only active CTP bundles. To activate, disable, delete, or recenter bundles using the CTP Menu: From the CTP Main Menu, select 1) Bundle Operations. Select the type of bundle. Copyright © 2018, Juniper Networks, Inc.
Page 144 Using Bundles to Create Logical Configurations for Physical Interfaces, CTP Release 7.3, CTPView Release 7.3 Select a bundle from the list. From the menu, select the option that you want to perform on the bundle: 4) Activate 5) Disable 6) Recenter Copyright © 2018, Juniper Networks, Inc.
Page 145: Querying Ctp Bundles
Table 57 on page 140 describes the fields in the state and counters sections of the display. The signaling configuration appears only if you changed the signaling configuration from the default configuration. Copyright © 2018, Juniper Networks, Inc.
Page 146 When direct drive is disabled, packets are forwarded based on information in the kernel’s IP stack. When direct drive is enabled, packets are forwarded directly between drivers on the local and remote CTP device. Copyright © 2018, Juniper Networks, Inc.
Page 147 (ST/RT) . Adaptive State For bundles that are configured as the adaptive end for adaptive clocking, displays the current state of the adaptive clock: Maintain (20 us) Maintain (968 us) N/A (Port Not RUNNING) Copyright © 2018, Juniper Networks, Inc.
Page 148 Maximum, average, and minimum buffer sizes observed in the last minute. BERT running sec Number of seconds the current update has been running. BERT sync sec Number of seconds that the local CTP device has been in sync with the remote CTP device. Copyright © 2018, Juniper Networks, Inc.
Page 149: Displaying The Netref Node Synchronization Information (Ctp Menu)
2) 2nd Priority, Reference 1: Disabled 3) 3rd Priority, Reference 2: Disabled 4) 4th Priority, Reference 3: Disabled 5) 5th Priority, Reference 4: Disabled 6) NetRef: Slave 7) 32 kHz Ref Output: 8) Query Node Sync Status Copyright © 2018, Juniper Networks, Inc.
Page 150 Displays the IP address of the NetRef master node assigned with priority 2. Priority 3 Displays the IP address of the NetRef master node assigned with priority 3. Priority 4 Displays the IP address of the NetRef master node assigned with priority 4. Copyright © 2018, Juniper Networks, Inc.
Page 151: Displaying The Running Ctp Bundle Configuration, State, And Counters
Table 59 on page 146 describes the fields in the state and counters sections of the display. The signaling configuration appears only if you changed the signaling configuration from the default configuration. Copyright © 2018, Juniper Networks, Inc.
Page 152 When direct drive is disabled, packets are forwarded based on information in the kernel’s IP stack. When direct drive is enabled, packets are forwarded directly between drivers on the local and remote CTP device. Copyright © 2018, Juniper Networks, Inc.
Page 153 Displays the size of IP packets that are created from data received at the T1/E1 interface. The CTP software calculates a default packet size based on the number of time slots configured, the type of interface (T1 or E1), and the type of signaling (CCS or CAS). Copyright © 2018, Juniper Networks, Inc.
Page 154 XOR packets over the IP network. Port Config Interface type Displays the type of interface. The type of interface that you select affects the default packet size and buffer sizes for the bundle. Copyright © 2018, Juniper Networks, Inc.
Page 155 Software or OAM link packets can check link partners and identify configuration errors. They can also differentiate between dead and alive states. IP Address Specifies an IP address for the other port of the redundant primary and backup pair. Copyright © 2018, Juniper Networks, Inc.
Page 156 RT (Ext Clock) Displays the current speed of the receive timing (RT) clock. Appears if the bundle is configured as the DTE, and clocking is set to DTE, All Clocked by Ext Clk (ST/RT) Copyright © 2018, Juniper Networks, Inc.
Page 157 The substitution maintains the bit count integrity of the data sent to the DTE or encryptor, but results in what appears to be a burst of errors with a duration equal to the size of the packet. Buffer restarts Number of times the buffer was restarted. Copyright © 2018, Juniper Networks, Inc.
Page 158 Maximum, average, and minimum buffer sizes observed in the last minute. Last counter clear Indicates the last time that the system counters were reset. This feature is supported on CTPOS release 6.6R3 and later for CESoPSN bundles created on CTP2000 series. Copyright © 2018, Juniper Networks, Inc.
Page 159: Monitoring Packet Creation And Reception And Packet Delay For Ctp Bundles
Packets to network from interface. Number of packets that were sent to the IP network from the interface. Pkts to NET ints Packets to network interrupts. Number of packets destined for the IP network that were processed by the software. Copyright © 2018, Juniper Networks, Inc.
Page 160 The time is measured from when a packet arrives from the Ethernet interface to when it is transmitted out the serial interface. You cannot display buffer sampling in CTPView. Copyright © 2018, Juniper Networks, Inc.
Page 161 Within the total number of samples, the largest sample measured in milliseconds. Packets in this sample experienced the least delay. Largest Buffer Jitter Difference between the largest sample measured and the smallest sample measured, in milliseconds. This number corresponds to system packet delay jitter. Copyright © 2018, Juniper Networks, Inc.
Page 163: Diagnostic Testing For Ctp Bundles Overview
The serial loop toward the interface loops data arriving from the serial interface that is destined for the IP network back to the serial interface. The data is still transmitted from Copyright © 2018, Juniper Networks, Inc.
Page 164: Serial Loop To The Network
Configuring Serial Loops for CTP Bundles (CTPView) on page 161 BERT Testing for CTP Bundles Overview The CTP series provides Bit Error Rate Tests (BERT) for bundles. Each bundle can have a BERT transmitter and receiver that can transmit and receive a pseudorandom sequence of data using a pattern that you specify.
Page 165: End-To-End Bert For Ctp Bundles Overview
To receive BERT reception from the network, start BERT reception on each bundle from the IP network as shown in Figure 20 on page 159. Figure 20: End-to-End BERT Reception CTP device CTP device BERT RX Customer Customer IP network Equipment Equipment BERT RX Copyright © 2018, Juniper Networks, Inc.
Page 166 The result is that end-to-end BERT transmission and reception are running as shown in Figure 21 on page 160. Figure 21: End-to-End BERT Transmission and Reception CTP device CTP device BERT TX BERT RX Customer Customer IP network Equipment Equipment BERT RX BERT TX Copyright © 2018, Juniper Networks, Inc.
Page 167: Configuring Diagnostic Testing For Ctp Bundles
A list of bundles configured on the CTP device appears. In the table of bundles, select the bundle for which you want to configure a serial loop. Configure the serial loop as described in Table 62 on page 162. Copyright © 2018, Juniper Networks, Inc.
Page 168: Configuring Serial Loops For Ctp Bundles (Ctp Menu)
From the CTP Main Menu, select 1) Bundle Operations. Select 1) CTP. Select a bundle from the list. Select 8) Runtime Diags. Select 1) Serial Loop. Configure the Serial Loop option as described in Table 63 on page 163. Copyright © 2018, Juniper Networks, Inc.
Page 169: Configuring Bert Testing For Ctp Bundles (Ctpview)
A list of bundles configured on the CTP device appears. In the table of bundles, select the bundle for which you want to configure BERTs. Configure the BERT parameters as described in Table 64 on page 164. Copyright © 2018, Juniper Networks, Inc.
Page 170 BERT has been established. The Error Cnt should increment by one. Related BERT Testing for CTP Bundles Overview on page 158 Documentation Displaying BERT Status and Counters for CTP Bundles (CTPView) on page 167 Copyright © 2018, Juniper Networks, Inc.
Page 171: Configuring Bert Testing For Ctp Bundles (Ctp Menu)
Rx from NET—BERT pattern is received from the The BERT receiver does not disrupt the existing data network. flow in either direction. Rx from I/F—BERT pattern is received from the interface. Copyright © 2018, Juniper Networks, Inc.
Page 172 BERT has been established. pattern. Related BERT Testing for CTP Bundles Overview on page 158 Documentation Displaying BERT Status and Counters for CTP Bundles (CTP Menu) on page 168 Copyright © 2018, Juniper Networks, Inc.
Page 173: Displaying Bert Status And Counters For Ctp Bundles
A list of bundles configured on the CTP device appears. In the table of bundles, select the bundle that you want to view. The BERT configuration and counters page appears. Table 66 on page 168 describes the status and the counter fields. Copyright © 2018, Juniper Networks, Inc.
Page 174: Displaying Bert Status And Counters For Ctp Bundles (Ctp Menu)
From the CTP Main Menu, select 1) Bundle Operations. Select the type of bundle. Select a bundle from the list. Select 8) Runtime Diags. Select 6) BERT counts. Table 67 on page 169 describes the BERT status and counters. Copyright © 2018, Juniper Networks, Inc.
Page 175 NO—The local CTP device is not in sync with the remote device. Related BERT Testing for CTP Bundles Overview on page 158 Documentation Configuring BERT Testing for CTP Bundles (CTP Menu) on page 165 Copyright © 2018, Juniper Networks, Inc.
Page 177: Packets
Enter a number from 0 through 255. snmp trap second of generating a trap before the trap is actually A setting of 0 means that no SNMP trap is generated. generated for missing packets. Copyright © 2018, Juniper Networks, Inc.
Page 178 A setting of 0 means that no SNMP trap is generated. Late packets are packets that arrived too generated for late packets. late at the CTP device to be processed out the interface. Copyright © 2018, Juniper Networks, Inc.

Juniper CTP Series Manual

Chapter 1 Overview of CTP Bundles

Chapter 2 Configuring CTP Bundles

Chapter 3 Activating, Disabling, Deleting, or Recentering CTP Bundles

Chapter 4 Querying CTP Bundles

Chapter 5 Monitoring Packet Creation and Reception and Packet Delay for CTP Bundles

Chapter 6 Diagnostic Testing for CTP Bundles Overview

Chapter 7 Configuring Diagnostic Testing for CTP Bundles

Chapter 8 Displaying BERT Status and Counters for CTP Bundles

Chapter 9 Reducingthenumberofsnmptrapsgeneratedforlateandmissing

Quick Links

Related Manuals for Juniper CTP Series

Summary of Contents for Juniper CTP Series

Table of Contents
