How To Install The Battery

1. Raise the operator seat.

2. Install the battery (E, Figure 32) into the battery compart-

ment, orientating it in the wireform (D) as shown.

3. Secure the battery with the battery strap (C), hooking the

loose end onto the wireform.

4. Connect the RED positive (+) cables (B) to the positive

terminal (+) on the battery with the removed hardware.

5. Connect the black negative (-) cable (A) to the negative

terminal (-) on the battery with the removed hardware.

WARNING

Always connect the BLACK negative (-) cable last.

6. Apply a small amount of grease over the terminals to pre-

vent corrosion.

7. Reinstall the positive terminal cover (F) over the positive

terminal.

WARNING

Always shield the positive terminal with the positive termi-

nal cover.

How To Store The Battery

If the unit is to be stored out of season, it is recommended

the battery be removed, charged and stored.

1. Remove the battery. Refer to "How To Remove The

Battery".

2. Charge the battery. Refer to "How To Charge The

Battery".

3. Store the battery in an area away from the unit on a

wood surface. DO NOT STORE THE BATTERY ON A

CONCRETE SURFACE.

Storage

1. Thoroughly clean the unit by removing all grass clippings

and debris.

2. Perform maintenance and lubrication as required.

3. Drain the fuel from the fuel tank (unless using a fuel sta-

bilizer - Refer to "Fuel System").

4. Start the engine and allow it to run until the engine runs

out of fuel. This allows the carburetor and fuel system to

remain clean during storage.

5. Remove and store the battery. Refer to "How To Store

The Battery".

Fuel System

Fuel can become stale when stored over 30 days. Stale

fuel causes acid and gum deposits to form in the fuel sys-

tem or on essential carburetor parts. To keep fuel fresh, use

Briggs & Stratton Advanced Formula Fuel Treatment &

Stabilizer, available wherever Briggs & Stratton genuine ser-

vice parts are sold.

There is no need to drain gasoline from the engine if a fuel

stabilizer is added according to instructions. Run the engine

for two (2) minutes to circulate the stabilizer throughout the

fuel system before storage.

If gasoline in the engine has not been treated with a fuel sta-

bilizer, it must be drained into an approved container. Run the

engine until it stops from lack of fuel. The use of a fuel sta-

bilizer in the storage container is recommended to maintain

freshness.

Engine Adjustments And Repairs

Engine adjustments and/or repairs should be performed by

an authorized dealer.

Rider Adjustments And Repairs

The following adjustment and repair items can be made by

the owner. However, it is recommended that they be made by

an authorized dealer.

How To Inspect The Mower Blade

WARNING

Wear heavy leather gloves when handling or working

around cutting blades. Blades are extremely sharp and

can cause severe injury. DO NOT use a cutting blade that

shows signs of excessive wear or damage.

Inspect the blade frequently for signs of excessive wear or

damage (Figure 33):

(A) New blade;

(B) Wear limit (notch starts);

with new blade. Contact your authorized dealer.

How To Sharpen The Mower Blade

Contact an authorized dealer for assistance regarding mower

blade sharpening.
