ENGINE
First 5 Hours
• Change engine oil
Every 8 Hours or Daily
• Check engine oil level
Every 25 Hours or Annually *
• Clean engine air filter and pre-cleaner **
Every 50 Hours or Annually *
• Change engine oil
• Replace oil filter
Annually
• Replace air filter
• Replace pre-cleaner
See Dealer Annually to
• Inspect muffler
• Replace spark plug
• Replace fuel filter
• Clean engine air cooling system
* Whichever comes first
** Clean more often in dusty conditions or when airborne
debris is present.
Engine Maintenance
How To Change The Engine Oil
Used oil is a hazardous waste product and must be disposed
of properly. Do not discard with household waste. Check with
your local authorities, service center, or dealer for safe dis-
posal/recycling facilities.
1. Place bricks or wooden blocks under the front wheels to
lower the rear of the engine.
2. Loosen or remove the oil fill cap on the engine.
3. Place a 2 quart minimum capacity container under the
end of the oil drain (Figure 23).
4. Remove or open the oil drain plug (A or B, Figure 23),
depending upon the type of oil drain plug the engine is
equipped with.
NOTE: Location of oil drain may vary according to model.
5. After all the oil has drained, replace or close the drain
plug, and wipe up any oil that may have spilled. Dispose
of used oil properly.
6. Fill the engine with new oil. Refer to "How To Check/Add
Oil" in the Operation Section.
How To Change The Oil Filter (if equipped)
Some models are equipped with oil filter. For replacement
intervals, see the Maintenance chart.
1. Drain the oil from the engine. Refer to "How To Change
The Engine Oil".
2. Remove the oil filter (A, Figure 24) and dispose of prop-
erly.
NOTE: Location of oil filter may vary according to model.
3. Before you install the new oil filter, lightly lubricate the oil
filter gasket with fresh, clean oil.
4. Install the oil filter by hand until the gasket contacts the
oil filter adapter, then tighten the oil filter 1/2 to 3/4 turns.
5. Add oil. Refer to "How to Check/Add Oil" in the Operation
section.
6. Start and run the engine. As the engine warms up, check
for oil leaks.
7. Stop the engine and check the oil level. It should be at
the top of the full indicator on the dipstick.
How To Service The Air Filter
WARNING
Fuel and its vapors are extremely flammable and explo-
sive. Fire or explosion can cause severe burns or death.
• Never start or run the engine with the air cleaner
assembly (if equipped) or the air filter (if equipped)
removed.
NOTICE
Do not use pressurized air or solvents to clean the filter.
Pressurized air can damage the filter and solvents will dis-
solve the filter.
Flat Air Filter
1. Pull up on the cover handle (A, Figure 25). Rotate the
cover handle toward the engine and then remove the
cover (B).
2. Remove the pre-cleaner (C), if equipped, and the filter
(D).
3. To loosen debris, gently tap the filter on a hard surface. If
the filter is excessively dirty, replace with a new filter.
4. Wash the pre-cleaner in liquid detergent and water. Then
allow it to thoroughly air dry. Do not oil the precleaner.
5. Assemble the dry pre-cleaner and the filter into the
engine base (E).
6. Align the tabs (F) on the cover with the slots (G) in the
blower housing. Rotate the cover handle back and push
down to lock in place.
Cylindrical Cartridge Air Filter
1. Remove the fasteners (A, Figure 26) and the air filter
cover (B).
2. To remove the filter (C), lift the end of the filter and then
pull the filter off the intake (D).
