Page 1 Migrating to the Avaya S8700 Series Media Servers Release 2.2 555-245-110 Issue 4 January 2005...
Page 2 • System administration documents Warranty • Security documents Avaya Inc. provides a limited warranty on this product. Refer to your • Hardware-/software-based security tools sales agreement to establish the terms of the limited warranty. In • Shared information between you and your peers addition, Avaya’s standard warranty language as well as information...
Page 3 • A reorder tone is received. 04DU9-IKN 6.0Y RJ48C Avaya attests that this registered equipment is capable of providing users access to interstate providers of operator services through the use of 04DU9-ISN 6.0Y RJ48C access codes. Modification of this equipment by call aggregators to block...
Page 4 Contact the state public utility commission, public service E-mail: totalware@gwsmail.com commission or corporation commission for information. For the most current versions of documentation, go to the Avaya support This equipment, if it uses a telephone receiver, is hearing aid compatible. Web site: http://www.avaya.com/support.
Page 5: Table Of Contents
Sending us comments ....... . . Chapter 1: Migrating legacy platforms to the Avaya S8700 or S8710 Media Server.
Page 6 DEFINITY ECS CSI or DEFINITY ONE/S8100 in a CMC ... . . Avaya IP600 ........
Page 7 Preconversion administration (R, SI, CSI) ....Connecting to the processor ......Verifying system status .
Page 8 Troubleshooting the migration ......Returning replaced equipment ......8 Migrating to the Avaya S8700 Media Server...
Page 9 Chapter 2: Migrating from an S8500 Media Server to S8710 Media Server ..... . Basic Migration Steps ....... . . Verify hardware .
Page 10 Configuring the network parameters ..... . . Verifying connectivity to the network server ....10 Migrating to the Avaya S8700 Media Server...
Page 11 Installing the new license and Avaya authentication files ... Restoring the Linux migration upgrade set from the network ..Selecting the media server type ......
Page 12 ........12 Migrating to the Avaya S8700 Media Server...
Page 13: About This Documentation
About this documentation Overview This documentation, Migrating to the Avaya S8700 Series Media Servers provides procedures for the following: Migrating existing DEFINITY systems to the Avaya S8700 or S8710 Media Server Migrating a dedicated control network to a nondedicated control network...
Page 14: Conventions
We show commands and screens from the newest Communication Manager and see the most current documentation. Physical dimensions All physical dimensions are in English units followed by metric units in parentheses. Wire gauge measurements are in AWG followed by the diameter in millimeters in parentheses. 14 Migrating to the Avaya S8700 Media Server...
Page 15: Terminology
Terminology We use the following terminology in this documentation: Configuration is a general term that encompasses all references to an Avaya media server with media gateways running Communication Manager. Cabinet refers to a stack of media gateways (such as the G650) that are TDM-cabled together.
Page 16: User Input
System output on the screen is in bold type. Example The system displays the following message: The installation is in progress. Field names on the screen are in bold type. Example Type y in the Message Transfer? field. 16 Migrating to the Avaya S8700 Media Server...
Page 17: Downloading This Documentation And Updates From The Web
(http://support.avaya.com). You must have access to the Internet and a copy of Adobe Reader installed on your personal computer. Avaya makes every effort to ensure that the information in this book is complete and accurate. However, information can change after we publish this documentation. Therefore, the Avaya Support Web site might also contain new product information and updates to the information in this book.
Page 18: Related Resources
Maintenance and repair, call the Avaya National Customer Care Support Line at 1-800-242-2121 Toll fraud, call Avaya Toll Fraud Intervention at 1-800-643-2353 International For all international resources, contact your local Avaya authorized dealer for additional help. 18 Migrating to the Avaya S8700 Media Server...
Page 19: Trademarks
All trademarks identified by the ® or are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. Sending us comments Avaya welcomes your comments about this book. To reach us by: Mail, send your comments to: Avaya Inc.
Page 20 About this documentation 20 Migrating to the Avaya S8700 Media Server...
Page 21: Chapter 1: Migrating Legacy Platforms To The Avaya S8700 Or S8710 Media Server
194 Migrating from existing DEFINITY and Linux platforms These procedures are for migrating from existing DEFINITY and Linux platforms to the Avaya S8700 or S8710 Media Server configuration. The S8700 or S8710 Media Server can be either a Multi-Connect configuration or an IP-Connect configuration.
Page 22: Migration Paths
However, when migrating from an S8100, the only supported method of moving translations is to freeze the translations and send them to Avaya’s Software Technical Support (STS) group. STS then returns the translation reports and translation files through email to the project manager before the migration.
Page 23 Migration paths Table 1: DEFINITY system releases migratable to the S8700 or S8710 Multi-Connect configuration Software Release Source Platform S8500 to S8700 to S8700 S8710 DEFINITY Release G3V4 DEFINITY Release G3s/si (w/Intel 386) DEFINITY Release 5 DEFINITY Release 6 DEFINITY Release 6 with SREPN DEFINITY Release 7 DEFINITY Release 8 DEFINITY Release 9...
Page 24 Migrating legacy platforms to the Avaya S8700 or S8710 Media Server Table 2: Product releases migratable to the S8700 or S8710 IP-Connect configuration Software Release Source Platform S8100/ S8100/ S8500 S8700 CMC1 G600 S8710 (DEF1) (IP600) DEFINITY Release G3V4 DEFINITY Release G3s/si...
Page 25: Pre-Migration Setup
If the existing system does not have a magneto optical drive or if the MOST (From a magneto optical disk on page 40) will not be used, send the translation media to Avaya’s Software Technical Support (STS) group. - For R, collect the translations locally via a spare tape or removable media.
Page 26 CAT3 cable used with C-LAN; must use CAT5 or better for 100 Mbps speed. Verify that the Services laptop has the right hardware and software. See Installing and Configuring the Avaya S8700 Series Media Servers (03-300145) for the list of computer specifications.
Page 27 When you have finished installing the authentication file, Communication Manager will have a password for all Avaya logins, including craft. This password is unique to the customer’s media server. You can use the password the next time you log in as craft, provided you access the media server through the Services port.
Page 28: Day Of Migration
Migrating legacy platforms to the Avaya S8700 or S8710 Media Server The TN750 Announcement circuit packs are not supported in the S8700 or S8710 Media Servers. The announcements translations will come over to the S8710 or S8710; however, the circuit pack locations need to be changed to the TN2501AP Voice Announcement over LAN (VAL) circuit pack.
Page 29: Documentation Needed
Documentation needed Verify that you have all the equipment on site. See Installing and Configuring the Avaya S8700 Series Media Servers (03-300145) for the list of required hardware. Verify that the Services laptop has the right hardware and software. See Installing and Configuring the Avaya S8700 Series Media Servers (03-300145) for the list of computer and software specifications.
Page 30: Basic Migration Steps
Basic migration steps When migrating from DEFINITY platforms: Install the Avaya S8700 or S8710 Media Servers and, if Avaya supplied, the Ethernet switch(es), and uninterruptible power supplies (UPSs) in the 4-post, 19-inch rack as described in the Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703).
Page 31 Install the Avaya S8710 Media Servers either - in a 19-inch, 4-post rack on a 2-post rack. as described in the Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703). - on a pullout shelf attached to a 2-post rack.
Page 32: High-Level Overview
This section applies to the S8700 or S8710 Multi-Connect configuration only. Note: The migration from a DEFINITY ECS R or SI platform to the Avaya S8700 or S8710 Media Server with Avaya G650 Media Gateway (S8700 or S8710 Multi-Connect configuration) may be done in stages.
Page 33: Ipsi Placement Decisions
This stage consists of the physical rack installation of the S8700 or S8710 Media Servers, uninterruptible power supplies (UPSs), Ethernet switches, and connecting cables. After completing the physical installation, the components are configured, the license and Avaya authentication files are installed, and the software is upgraded and patched.
Page 34: Transferring Existing Translations
DEFINITY system greatly increases, meaning translations would be out of sync. Unless these translations are concurrently entered into Avaya Communication Manager, they will be lost at cutover. Replacing expansion interface and maintenance circuit packs,...
Page 35: Replacing Tone Clocks With Tn2312Bp Ipsi Circuit Packs In The Expansion Port Networks And Processor Port Network (Optional)
High-level overview Replacing tone clocks with TN2312BP IPSI circuit packs in the expansion port networks and processor port network (optional) Some PNs receive IPSI circuit packs. The TN2312BP Internet Protocol Server Interface (IPSI-2) circuit pack takes the place of the existing TN2182 Tone Clock circuit pack and terminates control communication with the S8700 or S8710 Media Servers.
Page 36: Cutting Over To S8700 Or S8710 Media Server Control
For information on other post-migration tasks, such as clearing alarms, backing up the media servers, enabling alarm reporting, and registering the system, see Installing and Configuring the Avaya S8700 Series Media Servers (03-300145) and go to the "Completing the installation administration" section.
Page 37: Migrating Translations
There is no supported method of moving translations directly to the Avaya S8700 or S8710 Media Server except for an S8100 with a Compact Modular Cabinet (CMC1) or G600 Media Gateway.
Page 38: Accessing The Media Server
3. In the Address field, type 192.11.13.6 and press Enter to bring up the login Web page. 4. Log in as craft or dadmin. 5. When asked "Do you want to suppress alarms?", select yes. 6. Click Launch Maintenance Web Interface to get to the Main Menu. 38 Migrating to the Avaya S8700 Media Server...
Page 39: Checking System Status
Migrating translations Checking system status To check the system status: 1. Under Server, click Status Summary. 2. Verify the following information Duplication link between the S8700 or S8710 Media Servers is Up Standby shadowing is On Standby Refreshed is Yes Verifying license file To verify the license file: 1.
Page 40: Transferring Translations (Multi-Connect Only)
The Magneto Optical Server Tool (MOST) is used to transfer translation files from a Magneto Optical disk to an Avaya S8700 or S8710 Media Server. This tool is used only when migrating call processing translations on a DEFINITY ECS R to an Avaya S8700 or S8710 Media Server in a Multi-Connect configuration only.
Page 41 Migrating translations Terminal emulation may be used when connection to a media server command line interface (CLI) or a SAT session is needed. Terminal emulation port settings: 9600 baud No parity 8 data bits 1 stop bit No flow control S8700 or S8710 Disconnecting from the active media server 1.
Page 42 8. If the file sizes are still different, escalate the problem through the appropriate channels. 10. S8700 MC: Eject the flash adapter from the media server. <_mSysID>S8710 MC: Unplug MOST tool from the USB port. 42 Migrating to the Avaya S8700 Media Server...
Page 43 Migrating translations 11. Type sudo readmo -d and press Enter to disable MO read. 12. Type start -ac and press Enter to restart Communication Manager call processing. Figure 1: Magneto optical drive connection to S8700 Media Server cadlopt KLC 081402 1 2 3 4 +5VDC Figure notes:...
Page 44 3. SCSI cable and connector 6. Magneto Optical Drive S8700 or S8710 Disconnecting from the active media server 1. Unplug the laptop from the Services port on the back of the active media server. 44 Migrating to the Avaya S8700 Media Server...
Page 45: From A Pcmcia Flash Card
51. From a PCMCIA flash card Note: The PCMCIA flash card is used only with the S8700 Media Server. Note: Make sure you have the PCMCIA with the translations from Avaya’s Software Technical Support (STS) group. Issue 4 January 2005...
Page 46 S8700 only Restoring translation files 1. Place the PCMCIA flash card (STS provided) into the bottom slot of the PCMCIA drive in the active media server. See Flash card placement on page 47 46 Migrating to the Avaya S8700 Media Server...
Page 47 Migrating translations Figure 3: Flash card placement h1dlopt LJK 030102 Figure notes: 1. Media Server 3. Bottom slot of PCMCIA drive 2. PCMCIA flash card from STS 2. Under Data Backup/Restore, click View/Restore Data. 3. Select Local Directory and click View. The field automatically displays the default directory.
Page 48: Restoring Data For A Migration (S8710 Only)
1. Unplug the laptop from the Services port on the back of the active media server. Restoring data for a migration (S8710 only) The following procedure assumes the technician has already saved the customer’s conversion files (sent from the Avaya STS team) on the technician’s laptop. 48 Migrating to the Avaya S8700 Media Server...
Page 49 Migrating translations Accessing the media server from your laptop 1. Connect a crossover cable to the Services port on the back of the media server. 2. Launch the Web browser. 3. Type 192.11.13.6 in the Address bar and press Enter to bring up the logon Web page. 4.
Page 50 If the restore process fails, you get an error message stating the reason for the failure. If that is the case, then the translation file is not restored. Resolve the reason for the failure and restart the process. 50 Migrating to the Avaya S8700 Media Server...
Page 51: Adding Ipsi Translations To Communication Manager
5. Under Server, click Status Summary to verify that the standby media server has been refreshed. Do not continue until the standby media server has been refreshed. 6. Open a SAT session using Native Configuration Manager or Avaya Site Administration. 7. Login as craft or dadmin.
Page 52 IPSI Host Name Prefix: Primary Control Subnet Address: 172. 22. Secondary Control Subnet Address: OPTIONS Switch Identifier: A IPSI Control of Port Networks: disabled NOTE: * indicates data changed on the server 52 Migrating to the Avaya S8700 Media Server...
Page 53: Adding Ipsi Information
Migrating translations 2. Verify that the Primary Control Subnet Address and Secondary Control Subnet Address (if equipped) fields are correct. The subnet addresses must match the most significant 3 octets (the first 3 groups of digits in the subnet address) of the Server IP address filled in on the control network entry from the filled-out Electronic Preinstallation Worksheet (EPW).
Page 54 Enable QoS? y Primary IPSI QoS Parameters ------------ -------------- Location: 1A01 Call Control 802.1p: 6 Host: 172.22.22.174 Call Control DiffServ: 46 DHCP ID: ipsi-A01a Secondary IPSI -------------- Location: 1B01 Host: 172.22.22.175 DHCP ID: ipsi-A01b 54 Migrating to the Avaya S8700 Media Server...
Page 55: Setting Ipsi Duplication (High/Critical Reliability Only)
Migrating translations S8700 only 3. Verify the correct setting for the IP Control? field If IPSIs are in IP-connected PNs, then set the IP Control? field to y. If IPSIs are in fiber-connected PNs (CSS or ATM), then set the IP Control? field to y. If IPSIs are in fiber-connected PNs (direct-connect), then set the IP Control? field to y unless there is more than 1 IPSI.
Page 56: Setting Alarm Activation Level
Command Time-out (hours): 2 Control Channel Interchange: no System Clocks/IPSI Interchange: no 2. In the CPE Alarm Activation Level field, select none (default), warning, minor, or major, depending on the level the customer wants. 56 Migrating to the Avaya S8700 Media Server...
Page 57: Backing Up Translations
Migrating translations Backing up translations To back up translations: 1. S8700 MC: Replace the PCMCIA memory card (Local PC card) in the bottom PCMCIA slot of the active media server. S8710: Place a formatted flash card in the compact flash drive attached to a USB port. 2.
Page 58 If you select Save ACP translations prior to backup, the media server automatically saves the translations to its hard drive before saving it to the backup media. 7. Click Start Backup to begin the back up process. 58 Migrating to the Avaya S8700 Media Server...
Page 59: Migrating Hardware
These procedures are for migrating the hardware from existing platforms to the Avaya S8700 or S8710 Media Server with an Avaya G650 Media Gateway. The media server can be either a Multi-Connect configuration or an IP-Connect configuration. The migration procedures differ significantly because in the IP-Connect configuration, few of the old cabinets can be reused after the migration.
Page 60: Definity Ecs R Or Si In An Mcc
Migrating an existing DEFINITY ECS R or SI to the S8700 or S8710 IP Connect configuration requires moving allowable circuit packs to an Avaya G650 Media Gateway. The MCC cannot be reused. For specific information on how to do this, see Migrating from a DEFINITY ECS R or on page 101.
Page 61: Definity Ecs Csi Or Definity One/S8100 In A Cmc
S8700 IP Migrating an existing DEFINITY ECS SI to the S8700 or S8710 IP Connect configuration requires moving allowable circuit packs to an Avaya G650 Media Gateway. The SCC cannot be reused. For specific information on how to do this, see Migrating from a DEFINITY ECS R or on page 101.
Page 62: Avaya Ip600
Avaya IP600 You can only migrate an Avaya IP600 to an Avaya S8700 or S8710 IP Connect configuration. When migrating an existing Avaya IP600, you use one TN2312BP IPSI circuit pack to control the port network. You replace the processor circuit pack with the IPSI in the cabinet in the A position.
Page 63: Upgrading And Administering The Existing Hardware
122 Connecting media server and IPSI cables to Ethernet switch(es) See Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703) and the job aid titled Cabling Guide — MCC1 and SCC1 Media Gateway (555-245-771) for a connectivity guide.
Page 64: Upgrading Hardware In Each Port Network
EI-controlled PNs are assigned automatically to an IPSI at system initialization. The balancing of EI-controlled PNs amongst available IPSIs is also done automatically. Also, with Release 2.0 or later of Communication Manager, you are allowed to put an IPSI in a DS1-C-remoted port network. 64 Migrating to the Avaya S8700 Media Server...
Page 65: Standard (Simplex) Reliability Configuration
Upgrading and administering the existing hardware The following are the rules and guidelines for placement of IPSI circuit packs. Rules: When placing an IPSI in a DS1-C-remoted port network, make sure that the non-remoted IPSI is administered first and that the IP Control field is set to y. The IPSI in the DS1-C-remoted PN does not have to be set to no.
Page 66 9. Attach the other end of the short ribbon cable to the top connector on the component side of the TN775D circuit pack (red line on the bottom). See Duplex Reliability Ribbon Cable Connection on page 67. 66 Migrating to the Avaya S8700 Media Server...
Page 67 Upgrading and administering the existing hardware Figure 5: Duplex Reliability Ribbon Cable Connection 10. Push the tabs on the ends of the connector inward to lock the connector in place. 11. Thread the ribbon through the slot on the front panel. 12.
Page 68: High Or Critical Reliability Configuration (Mcc1)
Ribbon Cable Connector on page 66. 10. Thread the ribbon through the slot on the front panel. 11. Insert the TN775D Maintenance (EPN) circuit pack part way into the MAINTENANCE slot in carrier A. 68 Migrating to the Avaya S8700 Media Server...
Page 69 Upgrading and administering the existing hardware 12. Attach the other end of the short ribbon cable to the top connector on the component side of the circuit pack (red line on the bottom). See Duplex Reliability Ribbon Cable Connection page 67. 13.
Page 70 Figure 6: High/Critical Reliability Ribbon Cable Connection 70 Migrating to the Avaya S8700 Media Server...
Page 71: Connecting The Cat5 Cables To The Ipsi Circuit Packs
Connecting the CAT5 cables to the IPSI circuit packs To connect the CAT5 cables to the IPSI circuit packs: See Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703) and the job aid titled Cabling Guide — MCC1 and SCC1 Media Gateway (555-245-771) for a connectivity guide.
Page 72 TN2312AP/BP Internet Protocol Server Interface (IPSI/IPSI-2) circuit pack. 8. Push the tabs on the ends of the connector inward to lock the connector in place. See Ribbon Cable Connector on page 73. 72 Migrating to the Avaya S8700 Media Server...
Page 73 Upgrading and administering the existing hardware Figure 8: Ribbon Cable Connector 9. Thread the ribbon through the slot on the front panel. 10. Attach the other end of the short ribbon cable to the top connector on the component side of the TN775D Maintenance (EPN) circuit pack (red line on the bottom).
Page 74 13. For high or critical reliability configuration use the pass through tool to feed the long ribbon cable through media gateway A. See Ribbon cable placement using the pass through tool on page 75. 74 Migrating to the Avaya S8700 Media Server...
Page 75 Upgrading and administering the existing hardware Figure 10: Ribbon cable placement using the pass through tool M AJ M IN cadsrib2 KLC 032602 14. Plug the long ribbon cable into the bottom connector on the component side of the TN775D Maintenance (EPN) circuit pack.
Page 76 Figure 11: High/Critical Ribbon Cable Connection M IN A LA M AJ M IN A LA M AJ M IN cadsrib3 KLC 072502 cadsrib3 KLC 072502 76 Migrating to the Avaya S8700 Media Server...
Page 77 Upgrading and administering the existing hardware Figure 12: Cable routing through the TDM slot cadsrib4 KLC 032602 Figure notes: 1. Media Gateway B 3. TDM cable slot 2. Media Gateway A 18. Use the pass through tool to feed the long ribbon cable through media gateway B. 19.
Page 78 Figure notes: 1. Media Gateway B 3. Ground plate covering TDM cable opening. 2. Media Gateway A Note: All cables running between or exiting media gateways use the opening provided for TDM cables. 78 Migrating to the Avaya S8700 Media Server...
Page 79: Ordering Information
Cable Pass Through Kit Connecting the CAT5 cables to the IPSI circuit packs See Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703) and the job aid titled Cabling Guide — MCC1 and SCC1 Media Gateway (555-245-771) for a connectivity guide.
Page 80 3. Upper rear cover 2. Run the 25- or 50-m GREEN CAT5 cable from the Ethernet switch through the media gateway, using a cable pass-thru kit. See CAT5 cable in pass-thru kit on page 81. 80 Migrating to the Avaya S8700 Media Server...
Page 81 Upgrading and administering the existing hardware Figure 15: CAT5 cable in pass-thru kit M AJ M IN cadscat2 KLC 032602 3. Install the clamp on ferrite on the CAT5 Ethernet cable. See CAT5 cable run through the clamp-on ferrite on page 82. WARNING: The ferrite must be located as close to the exit of the media gateway as WARNING:...
Page 82 5. Replace the rear covers and the ground plate. Dress the CAT5 Ethernet cable to exit either the left or right side of the media gateway. See Replacement of the rear covers and the ground plate on page 84. 82 Migrating to the Avaya S8700 Media Server...
Page 83 Upgrading and administering the existing hardware 6. For high or critical reliability, repeat steps 1 through 5 for the IPSI circuit pack in media gateway B using a red CAT5 Ethernet cable. Figure 17: CAT5 cable connected to the IPSI M AJ M IN Issue 4 January 2005...
Page 84 Figure 18: Replacement of the rear covers and the ground plate cadscat5 KLC 032602 cadscat5 KLC 032602 Figure notes: 1. Ground Plate 84 Migrating to the Avaya S8700 Media Server...
Page 85: Installing Expansion Interface Circuit Packs
Upgrading and administering the existing hardware Installing Expansion Interface circuit packs To install the Expansion Interface circuit packs: Note: If the existing PPN has a TN776 or TN570 Expansion Interface circuit packs, you Note: must replace them with a TN570B Expansion Interface, vintage 7, or later circuit pack.
Page 86: Converting A Processor Port Network To A Port Network
Replacing the WP cables with twisted pair cables (IP600 only) Connecting the IPSI circuit pack to the Ethernet switch on the customer’s network Assigning an IP address to the IPSI circuit pack 86 Migrating to the Avaya S8700 Media Server...
Page 87: Preconversion Administration (R, Si, Csi)
Connecting to the processor To connect to the processor: 1. Use the computer used to access the cabinet 2. Open a SAT session using Native Configuration Manager or Avaya Site Administration. 3. Log in as craft. Verifying system status You want to check which groups are in or out of service before the migration and compare the list after the migration to make sure they are the same.
Page 88: Note Node Names And Ip Addresses
This section covers the following tasks: Connecting to the processor on page 89 Note node names and IP addresses on page 89 Saving translations on page 89 Note IP settings on page 90 88 Migrating to the Avaya S8700 Media Server...
Page 89: Connecting To The Processor
Note: processor. 1. Connect the Services laptop directly into the Avaya IP600 processor circuit pack If a TN795 Processor circuit pack, place the NIC card into the slot on the faceplate. If a TN2314 Processor circuit pack, plug the RJ45 connector directly into the RJ45 jack on the faceplate.
Page 90: Note Ip Settings
Note IP settings Note the IP settings assigned to the processor as they may be used for the Avaya S8700 or S8710 Media Server. Verify against the filled-out Electronic Preinstallation Worksheet. The following administration is done on the Services laptop connected to the processor circuit pack using telnet.
Page 91: Converting A Processor Port Network To A Port Network (Mcc)
Converting a processor port network to a port network (MCC) Converting a processor port network to a port network (MCC) Note: This section applies to the S8700 or S8710 Multi-Connect configuration only. Note: This section covers the following tasks: Removing the processor port network control carrier(s) on page 92 Installing the expansion control carrier and port carrier on page 93...
Page 92: Removing The Processor Port Network Control Carrier(S)
The AUX cable, that normally supplies the ground, will be disconnected. 2. Connect a 10 AWG (#25) (2.6 mm ) wire to pin 49 of the connecting block associated with the power failure transfer panel. 92 Migrating to the Avaya S8700 Media Server...
Page 93: Installing The Expansion Control Carrier And Port Carrier
Converting a processor port network to a port network (MCC) 3. Route the opposite end of the wire to an approved ground and connect. Note: You can cut over to having the media server control the other PNs at this time. Note: Only cutover at this time if you are not installing IPSI(s) in the PPN or the customer wants to minimize down time.
Page 94: Installing Ipsi And Maintenance Circuit Packs
To install the IPSI and maintenance card circuit packs: Connecting the CAT5 cables to the IPSI circuit packs See Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703) and the job aid titled Cabling Guide — MCC1 and SCC1 Media Gateway (555-245-771) for a connectivity guide.
Page 95: Installing Expansion Interface Circuit Packs
Converting a processor port network to a port network (MCC) Installing Expansion Interface circuit packs Note: If the existing PPN has a TN776 or TN570 Expansion Interface circuit packs, you Note: must replace them with a TN570B, vintage 7, or higher circuit pack. To install the Expansion Interface circuit packs: 1.
Page 96: Converting A Processor Port Network To A Port Network (Scc)
TN2312BP IP Server Interface circuit pack 700263502 IPSI adapter 700276389 Maintenance cable (attaches to IPSI adapter) 108865775 TN775D Maintenance circuit pack 700168727 Short ribbon cable—from maintenance board to IPSI in MCC1 A carrier 1 of 2 96 Migrating to the Avaya S8700 Media Server...
Page 97: Removing The Processor Port Network Control Cabinet
Converting a processor port network to a port network (SCC) Table 4: Required Migration Hardware 2 of 2 Comcode Description Quantity Green CAT5 Ethernet cable: 700170012 – 5-meter (16 feet) 700178056 – 25-meter (82 feet) 700178064 – 50-meter (164 feet) 700060643 TN2302AP IP Media Processor circuit pack 1 or more...
Page 98: Installing The Expansion Control Media Gateway
2. If needed, stack a third and fourth port media gateway on top of the first port media gateway. 3. Install the new CFY1B CURL unit on the back of control cabinet A. 4. Connect all the cables to the back of all the media gateways. TDM/LAN ICC-A, -B 98 Migrating to the Avaya S8700 Media Server...
Page 99: Installing Ipsi And Maintenance Circuit Packs
To install the IPSI and maintenance circuit packs: Connecting the CAT5 cables to the IPSI circuit packs See Quick Start for the Hardware Installation: Avaya S8700 Series Media Servers (555-245-703) and the job aid titled Cabling Guide — MCC1 and SCC1 Media Gateway (555-245-771) for a connectivity guide.
Page 100: Powering Up The Media Gateway(S)
Powering up the media gateway(s) To power up the media gateway(s): 1. Power up the media gateways. 2. Remove the emergency ground wire if used. 100 Migrating to the Avaya S8700 Media Server...
Page 101: Migrating From A Definity Ecs R Or Si
This section applies to the S8700 or S8710 IP-Connect configuration only. Note: These procedures explain how to migrate an existing DEFINITY ECS R or SI to the Avaya S8700 or S8710 IP Connect configuration. In this migration, you cannot reuse the existing cabinets;...
Page 102 700060643 TN2302AP IP Media Processor circuit pack 1 or more 700055015 TN799DP C-LAN circuit pack (to replace 1 or more TN799C) 848525887 IP Media Processor adapter 1/MedPro 1/C-LAN CAT5 cables 1/MedPro 1/C-LAN 102 Migrating to the Avaya S8700 Media Server...
Page 103 Migrating from a DEFINITY ECS R or SI Note: If you have a TN799C or earlier C-LAN circuit pack, you must replace it with a Note: TN799DP. And if you want to use 100 Mbps speed, you must use the IP Media Processor Amphenol Adapter and a CAT5 cable.
Page 104 DCP Digital Line, 2-wire 24-port (Category B only) TN2215 Analog Line TN2224CP DCP Digital Line, 2-wire, 24 ports; Firmware Download Enabled TN2242 TTC Digital 2-Mbit Trunk—Japan TN2302AP IP Media Processor; Firmware Download Enabled 2 of 3 104 Migrating to the Avaya S8700 Media Server...
Page 105 Migrating from a DEFINITY ECS R or SI Table 6: Allowable Circuit Packs and Circuit Modules 3 of 3 Apparatus Name code TN2305B ATM-CES Trunk/PN Interface—multimode fiber TN2306B ATM-CES Trunk/PN Interface—single mode fiber TN2312BP IP Server Interface TN2313AP DS1 Interface Trunk, 24 channels; Firmware Download Enabled TN2501AP VAL Announcement TN2793B...
Page 106 Tone Detector/Generator TN758 Modem Pool TN765 Processor Interface TN768 Tone-Clock TN772 Duplication Interface TN775C Maintenance TN776 Expansion Interface TN777B Network Control TN778 Packet Control TN780 Tone-Clock TN787K Multimedia Interface 2 of 3 106 Migrating to the Avaya S8700 Media Server...
Page 107 Migrating from a DEFINITY ECS R or SI Table 7: Non-Allowable Circuit packs and Circuit Modules 3 of 3 Apparatus Name code TN788B Multimedia Voice Conditioner TN790B Processor TN792 Duplication Interface TN794 Network Control/Packet Interface (NetPkt) TN798B Processor TN799/B/C Control Lan (C-LAN) TN1648B System Access/Maintenance TN1650B...
Page 108: Migrating Mcc Or Scc To G650 Media Gateways
CAUTION: powered down to when the circuit packs are relocated and the telephones and other stations and trunks are connected to the new Avaya G650 Media Gateways. All reusable circuit packs and their associated cables must be moved from the SCCs and the MCC carriers to the G650 Media Gateways.
Page 109: Removing The Circuit Packs
Migrating from a DEFINITY ECS R or SI Removing the circuit packs To remove circuit packs: CAUTION: Always wear an antistatic wrist strap when removing circuit packs and associated CAUTION: cables. 1. Remove all circuit packs. Store the circuit packs in static-proof packaging. 2.
Page 110: Placing Circuit Packs Into G650 Media Gateway
Public Switched Telephone Network (PSTN). For information on connecting the media gateways to the PSTN, see Installing and Configuring the Avaya S8700 Series Media Servers (03-300145) and go to the section titled "Connect the main distribution frame to stations and the public switched telephone network."...
Page 111: Converting A Processor Port Network To A Port Network (Cmc)
Note: If you want to make the system high reliability, then you cannot reuse the Note: Compact Modular Cabinets (CMCs). You must install Avaya G650 Media Gateways and move all the circuit packs to the G650. Note: This section applies only to the S8700 or S8710 IP-Connect configuration.
Page 112: Verifying Hardware
Processor circuit pack containing the Audix feature is being replaced with a TN2312BP Internet Protocol Server Interface (IPSI-2) circuit pack that does not have that feature. The existing processor circuit pack must be returned to Avaya. 112 Migrating to the Avaya S8700 Media Server...
Page 113: Converting The Control Cabinet To A Port Network
Converting a processor port network to a port network (CMC) Note: Customers also need to add an ED-1E568-70G1 DEFINITY Audix Slim board Note: and a TN2501AP Voice Announcement over LAN (VAL) circuit pack for announcements. Converting the control cabinet to a port network To convert the control cabinet to a port network, you must If CSI, remove the TN798 or TN2402 Processor circuit pack and replace the TN2182 Tone Clock circuit pack with a TN2312BP Internet Protocol Server Interface (IPSI-2) circuit...
Page 114: Powering Down The Control Cabinet
The TN2312BP Internet Protocol Server Interface (IPSI-2) circuit pack takes up Note: only one slot. 6. Insert the TN2312BP Internet Protocol Server Interface (IPSI-2) circuit pack into slot 2. 7. Attach the new label above the circuit pack slots. 114 Migrating to the Avaya S8700 Media Server...
Page 115: Replacing The Tn799C C-Lan Circuit Pack (If Necessary)
Converting a processor port network to a port network (CMC) Replacing the TN799C C-LAN circuit pack (if necessary) To replace the TN799C C-LAN circuit pack: 1. Remove the TN799C Control-LAN (C-LAN) circuit pack and place it in an antistatic carrier or bag.
Page 116: Converting A Processor Port Network To A Port Network (Ip600)
Green CAT5 Ethernet cable: 700170012 – 5-meter (16 feet) 700178056 – 25-meter (82 feet) 700178064 – 50-meter (164 feet) 700060643 TN2302AP IP Media Processor circuit pack 1 or more 1 of 2 116 Migrating to the Avaya S8700 Media Server...
Page 117 Audix feature is being replaced with a TN2312BP Internet Protocol Server Interface (IPSI-2) circuit pack that does not have that feature. The existing processor circuit pack must be returned to Avaya. Note: Customers also need to add an ED-1E568-70G1 DEFINITY Audix Slim board...
Page 118: Converting The Ip600 Control Chassis To A Port Network
Converting the IP600 control chassis to a port network To convert the Avaya IP600 control chassis to a port network, you must Replace the existing straight-wire WP cables, if present, with new twisted pair I/O cables. Replace the processor circuit pack with a TN2312BP IP server interface (IPSI) circuit pack.
Page 119: Replacing The Wp Cables
Converting a processor port network to a port network (IP600) Replacing the WP cables WP cables have straight, not twisted, wires. They may be mostly white with two red, or multi-colored. You must replace the WP cables, which connect the backplane to the rear connector panel, with Twisted Pair I/O cables.
Page 120 Figure 19: Fan Assembly Removal fndpremv LJK 102600 Figure 20: Proper Orientation for the Twisted Pair I/O Cables iodspair KLC 072602 Figure notes: 1. Top 4. Orange-black 2. No connects; no wires 5. Bottom 3. Violet-brown 120 Migrating to the Avaya S8700 Media Server...
Page 121: Replacing The Processor Circuit Pack
Converting a processor port network to a port network (IP600) Replacing the processor circuit pack To replace the processor circuit pack: 1. Remove the entire processor circuit pack and place it in an antistatic carrier or bag. You want it intact if you need to back out of the migration. 2.
Page 122: Postmigration Administration
The IPSI circuit packs associated with a nondedicated control network use the static addressing method. In rare cases they might use the DHCP addressing method. 122 Migrating to the Avaya S8700 Media Server...
Page 123: Using Dhcp Addressing
Postmigration administration Using DHCP addressing For the TN2312BP IPSI circuit packs to get IP addresses dynamically, you must first assign the switch ID (A through J) and the cabinet number (01 through 64) to each IPSI circuit pack. For G650 Media Gateways, a cabinet is defined as one or more media gateways connected by TDM cable, which is called a G650-rack-mount-stack.
Page 124 IPSI, the center of the "V" is filled in to form the bottom half of a diamond in the display. For duplicated control network, repeat these steps for the second IPSI in the cabinet. 124 Migrating to the Avaya S8700 Media Server...
Page 125: Using Static Addressing
Postmigration administration Using static addressing For the IPSI circuit packs to get static IP addresses, you must administer them directly through the Ethernet port connection on the IPSI faceplate (top port). See Connecting directly to the IPSI on page 125. Figure 21: Connecting directly to the IPSI cadlipsi KLC 031502 Figure notes:...
Page 126: Logging Into The Ipsi
Setting the control interface The following steps sets the control interface. 1. Type show control interface and press Enter. 2. Type show port 1 and press Enter to see the current settings. 126 Migrating to the Avaya S8700 Media Server...
Page 127: Setting The Vlan And Diffserv Parameters
Postmigration administration 3. Type set control interface ipaddr netmask and press Enter, where ipaddr is the customer-provided IP address and netmask is the customer provided subnet mask. 4. Type show control interface and press Enter. The IP address, subnet mask, and default gateway information will be displayed. Verify that the proper information was entered.
Page 128: Verifying Ipsi Translations
125. 4. Repeat for each IPSI circuit pack. Verifying IPSI translations To verify IPSI translations: 1. Type list ipserver-interface and press Enter. 2. Verify that the ISPI circuit pack(s) is translated. 128 Migrating to the Avaya S8700 Media Server...
Page 129: Verifying Ipsi Connectivity
Postmigration administration Verifying IPSI connectivity To verify IPSI connectivity: 1. Under Diagnostics, click Ping. 2. Select IPSIs with cab number (1–99) ___ carrier number ___. Fill in the blanks with the correct cabinet and carrier numbers. 3. Click Execute Ping. 4.
Page 130 NOTE: * indicates data changed on the server 2. Set the IPSI Control of Port Networks: field to enabled 3. Press Enter to effect the change. All the port networks are now controlled by the media server. 130 Migrating to the Avaya S8700 Media Server...
Page 131: Verifying Customer's Data
Postmigration administration Verifying customer’s data The new translations should include all the media gateway (chassis) and circuit pack administration, including the media gateway (chassis) and the circuit pack administration of the converted cabinets (chassis). Verify that the information is correct. Verifying circuit pack locations To verify circuit pack locations: 1.
Page 132: Check Link Status
Upgrade the firmware on the just installed TN2313BP IP Server Interface circuit pack if necessary. For information on how to do this, see "Upgrade the IPSI Firmware" in the section titled "Upgrading Software and Firmware," which is part of the Avaya S8300, S8500, and S8700 Media Server Library CD.
Page 133: Testing The Installation
Testing the installation Test the complete installation. See ‘‘Testing the Complete Configuration’’ in the Installation section, which is part of the Avaya S8300, S8500, and S8700 Media Server Library CD. Busying out trunks If you recorded any busyouts earlier, you need to make sure they are busied out after the conversion.
Page 134 134 Migrating to the Avaya S8700 Media Server...
Page 135: Chapter 2: Migrating From An S8500 Media Server To S8710 Media Server
(LSPs), if they are being used, before the S8710 Media Server takes control. Basic Migration Steps Install the Avaya S8710 Media Servers in a 19-inch, 4-post rack as described in the Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703). You need a second UPS.
Page 136: Verify Hardware
Avaya S8710 Media Servers Powerware 9125 uninterruptible power supply (UPS) (if Avaya-provided) 408357002 – US & Canada 408427409 – International 700181928 – Japan 408427656 SNMP Network Interface Adapter for UPS (if Avaya-provided) 1 of 2 136 Migrating to the Avaya S8700 Media Server...
Page 137: Before You Go On Site
Compact 4-slot flash drive 700290430 Compact flash media 700287964 Avaya Communication Manager CD for Linux Servers 700252828 Avaya S8300, S8500, S8700 Media Server Library CD (555-233-824) Green CAT5 Ethernet cables 700170012 – 5 meters (16 feet) 700178056 – 25 meters (82 feet) 700178064 –...
Page 138: Upgrade G350 Or G700 Media Gateways And Lsps (If Being Used)
1.720.444.5557). You must have the IL, FL, or product ID to get the password. To log in through the Services port as craft after you install the Avaya authentication file, use this password, which does not require an ASG challenge or response.
Page 139: Upgrade Firmware On Media Gateways And Media Modules
Upgrade firmware on media gateways and media modules For more detailed information on the firmware upgrade process, see Installation and Upgrades for the Avaya G700 Media Gateway and Avaya S8300 Media Server (555-234-100) or for more complete information. Upgrade software on the LSPs For more detailed information on the software upgrade process, see Installation and Upgrades for the Avaya G700 Media Gateway and Avaya S8300 Media Server (555-234-100).
Page 140 Connecting the S8710 Media Servers to the control network on page 150 On the S8500 Media Server: Shutting down the S8500 Media Server on page 151 Disconnecting the cables on page 151 140 Migrating to the Avaya S8700 Media Server...
Page 141: On The S8500 Media Server
On the S8500 Media Server On the S8500 Media Server Clearing the ARP cache on the laptop To clear the ARP cache: Note: Depending on your laptop computer’s operating system (generally Windows Note: 2000), you may need to clear the Address Resolution Protocol (ARP) cache before entering a new IP address.
Page 142: Checking For Translation Corruption
2. Insert a formatted 128-megabyte (MB) compact flash disk into the bottom slot of the drive. 3. From the menu, select Backup/Restore, then select Backup Now. 4. Select Avaya Call Processing (ACP) Translations and Local PC (this is the compact flash) and select the number of data sets to retain as the backup method.
Page 143: On Active S8710 Media Server
On active S8710 Media Server On active S8710 Media Server Powering up both media servers To power up the media servers: 1. Connect the AC power cord to both media servers and to the UPS units to power them up. 2.
Page 144: Setting Up Telnet (If Necessary)
4. 4. Type unset crlf and press Enter. 5. Type display and press Enter to verify that the settings changed. The message says Sending only CR 6. Close the dialog box. 144 Migrating to the Avaya S8700 Media Server...
Page 145: Installing Communication Manager
On active S8710 Media Server Installing Communication Manager To install Communication Manager: 1. Type telnet 192.11.13.6 and press Enter to view the first screen. Note: To navigate on these screens, use the arrow keys to move to an option, then Note: press the space bar to select the option.
Page 146 The reboot may take up to 3 minutes. The telnet session drops automatically. 5. Disconnect from the active media server and connect to the other media server. 6. Repeat Powering up both media servers on page 143 through Installing Communication Manager on page 145. 146 Migrating to the Avaya S8700 Media Server...
Page 147: Accessing The Media Server
You need to configure both media servers and install the new license file and software updates on each media server using the Avaya Installation Wizard (AIW). You can do it two ways: Import the data from the filled-out Electronic Preinstallation Worksheet (EPW).
Page 148: Restoring The Translations
Verify the same stations are on this server as were on the S8500 Media Server. 4. Type save trans and press Enter. 5. Perform the necessary administration (for example, add duplication administration). 6. When finished, type save trans and press Enter. 148 Migrating to the Avaya S8700 Media Server...
Page 149 On S8710 Media Servers 7. If the browser is not running, activate the browser with the Home page. Note: For the next step, do not continue until the Status Summary informs you that the Note: standby server memory is refreshed. 8.
Page 150: On The S8500 Media Server
S8710 Media Servers. 2. After approximately 30 minutes, verify the system is functioning satisfactorily. Check and clear alarms. If everything is satisfactory, continue to Shutting down the S8500 Media Server on page 151. 150 Migrating to the Avaya S8700 Media Server...
Page 151: On The S8500 Media Server
On the S8500 Media Server On the S8500 Media Server Shutting down the S8500 Media Server To shut down the S8500 Media Server: CAUTION: Do not unplug a functioning server without stopping all processes first. Failure to CAUTION: do this corrupts the hard drive. 1.
Page 152 Migrating from an S8500 Media Server to S8710 Media Server 152 Migrating to the Avaya S8700 Media Server...
Page 153: Chapter 3: Migrating From An S8700 Media Server To An S8710 Media Server
These procedures explain how to migrate existing S8700 Media Servers on release 1.x through 2.1 of Avaya Communication Manager to an S8710 Media Servers on release 2.1.1 or 2.2 with limited downtime. If the media servers are on release 1.0/1.1, you must upgrade them to release 1.3.2 before the migration.
Page 154: Day Of Migration
1.720.444.5557). You must have the IL, FL, or product ID to get the password. To log in through the services port as craft after you install the Avaya authentication file, use this password, which does not require an ASG challenge or response.
Page 155: Verifying Hardware
Pre-Migration Setup Install the Avaya S8710 Media Servers either - in a 19-inch, 4-post rack as described in the Quick Start for Hardware Installation: Avaya S8700 Series Media Servers (555-245-703). - on a pullout shelf attached to the existing 2-post rack.
Page 156 Servers documents CD (03-300151) 700169998 Blue CAT5 Ethernet crossover cable for duplication Yellow single-mode fiber optic cable with LC 700290422 connectors 700326382 – 4.6 meters (15 feet) – 100 meters (328 feet) 156 Migrating to the Avaya S8700 Media Server...
Page 157: Upgrading G350 Or G700 Media Gateways And Lsps (If Being Used)
Upgrade firmware on media gateways and media modules For more detailed information on the firmware upgrade process, see Installation and Upgrades for the Avaya G700 Media Gateway and Avaya S8300 Media Server (555-234-100) or for more complete information. Upgrading software on the LSPs For more detailed information on the software upgrade process, see Installation and Upgrades for the Avaya G700 Media Gateway and Avaya S8300 Media Server (555-234-100).
Page 158: Task List
You may be able to use the Upgrade Tool to upgrade the software on the S8300 Media Server, depending on the media server version. For more information see Installation and Upgrades for the Avaya G700 Media Gateway and Avaya S8300 Media Server (555-234-100). CAUTION: You must stop call processing on the LSPs during the migration process.
Page 159 Configuring the network parameters on page 174 Verifying connectivity to the network server on page 176 Installing the new license and Avaya authentication files on page 177 Restoring the Linux migration upgrade set from the network on page 177 Selecting the media server type...
Page 160: On The Active S8700 Media Server
1. Connect the laptop to the Services port (2) on the back of the active media server using a crossconnect CAT5 cable. Services laptop computer connected directly to the S8700 Media Server on page 161. 160 Migrating to the Avaya S8700 Media Server...
Page 161: Accessing The Media Server
On the active S8700 Media Server Figure 23: Services laptop computer connected directly to the S8700 Media Server cadlsrvr KLC 030402 Figure notes: 1. Services laptop 3. NIC adapter cable (if necessary) 2. Network Interface Card (NIC) 4. Black CAT5 crossconnect cable Accessing the media server To access the media server: 1.
Page 162: Clearing Alarms
1. Type display errors and press Enter. Look for type 18 errors and record any trunks that are busied out, so you can return them to their busied-out state after the upgrade. 162 Migrating to the Avaya S8700 Media Server...
Page 163: Checking Clock Synchronization
1. Type status sync and press Enter to verify that the clock synchronization is good. 2. Make sure the Switching Capabilities field shows enabled. Note: Because of a change in Release 1.3 of the Avaya Communication Manager, you Note: do not need to disable Terminal Translation Initialization (TTI) before an upgrade or migration or enable it afterwards.
Page 164: Busyout Mmi Circuit Packs (Duplicated Control Only)
1. Under Server Upgrades, click Software Version to see what software release is on the media server. 2. If release 1.0 or 1.1, upgrade to release 1.3.2. If release 1.2 or 1.3, apply the upgrade patch. 164 Migrating to the Avaya S8700 Media Server...
Page 165: Backing Up The Linux Migration Upgrade Set To The Network
Backing up the Linux migration upgrade set to the services laptop on page 166. Note: When backing up the files, the system backs up the necessary Avaya Call Note: Processing (ACP) translations and other files and labels it upgrade. Note: If the customer’s FTP server is not available, go to...
Page 166: Backing Up The Linux Migration Upgrade Set To The Services Laptop
2. Under Security, click FTP. The system displays the FTP window. 3. Click Start Server. 4. Under Server Upgrades, click Linux Migration (Backup / Restore). The system displays the Linux Migration - Backup / Restore window. 166 Migrating to the Avaya S8700 Media Server...
Page 167 On the active S8700 Media Server 5. Select Initiate new backup or restore and click Submit. The system displays the Linux Migration - Backup / Restore Initiate window. 6. In the Backup Method section, select FTP. 7. In the following fields: User Name field: type anonymous Password field: enter your email ID Host Name field: enter the exact server hostname for the server you are on...
Page 168 14. For the password, type your email ID and press Enter. 15. Type cd pub and press Enter. 16. Type bin and press Enter to make the transfer in a binary format. 168 Migrating to the Avaya S8700 Media Server...
Page 169: Recording The Product Id
On the standby S8700 Media Server 17. Type get name where name is the name of the Linux migration upgrade set and press Enter. 18. Log off the system. Recording the Product ID To record the Product ID: 1. Click Start > Run to open the Run dialog box. 2.
Page 170: Shutting Down The S8700 Media Server
Be careful not to push the UID button located above the power button. If you push CAUTION: this button, it will reset the UID on the media server. 4. Push the power button. 170 Migrating to the Avaya S8700 Media Server...
Page 171: Accessing The Media Server
On first S8710 Media Server Accessing the media server To access the media server: 1. Clear the ARP cache from the laptop if necessary. See Clearing the ARP cache on the laptop on page 160 and return here. 2. Connect the laptop to the Services port (2) on the back of the media server using a crossconnect cable.
Page 172: Installing Communication Manager
Migrating from an S8700 Media Server to an S8710 Media Server Installing Communication Manager The following steps install Avaya Communication Manager on the media server. Note: Use a telnet session to access the information on the CD. Note: 1. Type telnet 192.11.13.6 and press Enter to view the first screen.
Page 173: Reaccessing The Media Server Using Telnet
On first S8710 Media Server 3. On the Select Release Version screen, make sure the Build line and <OK> is highlighted. Press Enter to partition the hard drive and reformat the partitions. Once the drive is properly configured, the program begins the installation process and reports the progress.
Page 174: Checking The Software Version
You must have the host name, IP address, subnet mask and default gateway for the two media servers and the active server as well as the IP address for the Ethernet port connecting to the customer’s network. 174 Migrating to the Avaya S8700 Media Server...
Page 175 On first S8710 Media Server To configure the network parameters: 1. Under Server Configuration, click Configure Server to open the first page (Select server type) of the Configure Server process. 2. Select the appropriate server type and click Continue. 3. Click Continue through the Review Notices to get to the Specify how you want to use this wizard page.
Page 176: Verifying Connectivity To The Network Server
5. Ethernet 4 - to customer’s network 2. Ethernet 1 - to Services laptop if dedicated control network (cross-connect CAT5 cable) (straight-through CAT5 cable) 3. Ethernet 2- to duplicated media 6. Not used server (cross-connect CAT5 cable) 176 Migrating to the Avaya S8700 Media Server...
Page 177: Installing The New License And Avaya Authentication Files
Installing the new license and Avaya authentication files For a migration, you need to load a new license file and Avaya authentication file. 1. Under Security, click License File, select Install the license previously downloaded, then click Submit to install the license file.
Page 178 Backup: 0: Restore of <filepath/filename> is completed successfully. This procedure assumes that the license and authentication file are on the services laptop. The following steps downloads the files to the media server. 9. Under Miscellaneous, click Download Files. 178 Migrating to the Avaya S8700 Media Server...
Page 179: Selecting The Media Server Type
12. When all the files to be uploaded show in the fields, click Load File to upload all the files to the media server. Once the license and Avaya authentication files are downloaded to the media server, you must install them.
Page 180: Restoring The Linux Migration Upgrade Set From The Services Laptop
1. Access the media server. See Accessing the media server on page 161 and return here. 2. Under Server Upgrades, click Linux Migration (Backup / Restore). The system displays the Linux Migration - Backup / Restore window. 180 Migrating to the Avaya S8700 Media Server...
Page 181 On first S8710 Media Server 3. Select Initiate new backup or restore and click Submit. The system displays the Linux Migration - Backup / Restore Initiate window. 4. In the Restore Method section, select Local Directory. 5. Type /var/home/ftp/pub as the destination location of the Linux migration upgrade set and press Enter.
Page 182 The system displays the Linux Migration - Backup / Restore Status window. This window may display a BACKUP COMPLETE message with possible series 200 error messages. You can ignore these series 200 error messages and proceed with restoring the Linux migration upgrade set. 182 Migrating to the Avaya S8700 Media Server...
Page 183: Installing Software Update (If Any)
On first S8710 Media Server Installing software update (if any) Note: Skip this procedure if there is no Communication Manager software update file to Note: install. Use a telnet session to install the software update file. 1. Click Start > Run to open the Run dialog box. 2.
Page 184: Verifying Media Server Configuration
1. Repeat tasks Powering up the media server on page 170 through Configuring the network parameters on page 174 and return here. CAUTION: Make sure you restore the files from media server 2. CAUTION: 184 Migrating to the Avaya S8700 Media Server...
Page 185: Installing The New License And Avaya Authentication Files
On second S8710 Media Server Installing the new license and Avaya authentication files For a migration, you need to load a new license file and Avaya authentication file. 1. Under Security, click License File, select Install the license previously downloaded, then click Submit to install the license file.
Page 186: Restoring The Linux Migration Upgrade Set From The Services Laptop
183 for media server 2 and return here. Verifying media server configuration To verify the media server configuration: 1. Repeat task Verifying media server configuration on page 184 on the active server and return here. 186 Migrating to the Avaya S8700 Media Server...
Page 187: Transferring System Control To The S8710 Media Servers
Transferring system control to the S8710 Media Servers Transferring system control to the S8710 Media Servers CAUTION: There may be an interruption of service up to 30 minutes if moving the Ethernet CAUTION: switch(es) and UPSs. Moving Ethernet cables Moving the CAT5 cables from the S8700 Media Servers to the S8710 Media Servers transfers control to the S8710 Media Servers.
Page 188: Moving Cables To The S8710 Media Server (Media Server 2)
160 and return here. 2. If not already connected to the standby media server, connect to it. 3. Log in. (See Accessing the media server on page 161 and return here.) 188 Migrating to the Avaya S8700 Media Server...
Page 189: Pinging All The Connections To The Media Server
On the standby S8710 Media Server Pinging all the connections to the media server To ping all connections to the media server: 1. Under Diagnostics, click Ping. 2. Select Other server(s), All IPSIs, UPS(s), Ethernet switches and click Execute Ping. Backing up files on the media server To back up files on the media server: 1.
Page 190: Setting The Product Id
1. Clear the ARP cache on the laptop if necessary. See Clearing the ARP cache on the laptop on page 160 and return here. 2. Connect to the active media server. 3. Log in. See Accessing the media server on page 161. 190 Migrating to the Avaya S8700 Media Server...
Page 191: Resolving Alarms
2. Select the server alarms to be cleared and click Clear. 3. Resolve new alarms since the migration using SAT commands and the Maintenance Commands for Avaya Communication Manager 2.1, Media Gateways and Servers and Maintenance Alarms for Avaya Communication Manager 2.1, Media Gateways and Servers books.
Page 192: Logging Off All Administration Applications
Disconnect the laptop from the media server. Registering the system Follow the existing process and procedures to register the Avaya S8710 Media Server. Removing customer files from the services laptop Remove the customer Linux migration upgrade set from the services laptop.
Page 193: Chapter 4: Migrating A Dedicated Control Network To A Nondedicated Control Network
Chapter 4: Migrating a dedicated control network to a nondedicated control network You can migrate a previously dedicated (private) control network to one that is nondedicated (through the customer’s network). To do this, you must be on Release 2.0 or later of Communication Manager.
Page 194: Upgrading A Tn2312Ap To A Tn2312Bp Ip Server Interface Circuit Pack
Command Time-out (hours): 2 Control Channel Interchange: no System Clocks/IPSI Interchange: no 2. In the CPE Alarm Activation Level field, select none (default), warning, minor, or major, depending on the level the customer wants. 194 Migrating to the Avaya S8700 Media Server...
Page 195: Replacing The Circuit Pack
You may need to upgrade the firmware on the IPSI(s). Each IPSI must be on the most current and same firmware load. For the most current firmware load, go to the Avaya Support Web page (http://avaya.com/support) and click Software and Firmware Downloads.
Page 196 196 Migrating to the Avaya S8700 Media Server...
Page 197: Index
Index Index ..copying files to the media server copying translations ... . . from PCMCIA flashcard ..accessing standby media server .
Page 198 TN799C with a TN799DP ....moving Ethernet cables WP cables with twisted pair I/O cables 198 Migrating to the Avaya S8700 Media Server...
Page 199 Index ....resolving alarms tone clock circuit packs ....
Page 200 Index 200 Migrating to the Avaya S8700 Media Server...

This manual is also suitable for:

S8700S8710

Avaya S8700 Series Manual

About this Documentation

Overview

Audience

Using this Documentation

Conventions

Downloading this Documentation and Updates from the Web

Safety Labels and Security Alert Labels

Related Resources

Technical Assistance

Trademarks

Sending Us Comments

Chapter 1: Migrating Legacy Platforms to the Avaya S8700 or S8710 Media Server

Migrating from Existing DEFINITY and Linux Platforms

Migration Paths

Pre-Migration Setup

Documentation Needed

Basic Migration Steps

High-Level Overview

Migrating Translations

Migrating Hardware

Upgrading and Administering the Existing Hardware

Converting a Processor Port Network to a Port Network

Converting a Processor Port Network to a Port Network (MCC)

Converting a Processor Port Network to a Port Network (SCC)

Migrating from a DEFINITY ECS R or si

Converting a Processor Port Network to a Port Network (CMC)

Converting a Processor Port Network to a Port Network (IP600)

Postmigration Administration

Chapter 2: Migrating from an S8500 Media Server to S8710 Media Server

Basic Migration Steps

Verify Hardware

Before You Go on Site

Upgrade G350 or G700 Media Gateways and Lsps (if Being Used)

On the S8500 Media Server

On Active S8710 Media Server

On S8710 Media Servers

On the S8500 Media Server

On the S8710 Media Servers

On the S8500 Media Server

Chapter 3: Migrating from an S8700 Media Server to an S8710 Media Server

Pre-Migration Setup

On the Active S8700 Media Server

On the Standby S8700 Media Server

On First S8710 Media Server

On Second S8710 Media Server

Transferring System Control to the S8710 Media Servers

On the Standby S8710 Media Server

On the Active S8710 Media Server

Chapter 4: Migrating a Dedicated Control Network to a Nondedicated Control Network

Upgrading a TN2312AP to a TN2312BP IP Server Interface Circuit Pack

Index

Quick Links

Related Manuals for Avaya S8700 Series

Summary of Contents for Avaya S8700 Series
