• Two Pmod 2x6 connectors (one male pin header, one right-angle receptacle)
• VITA 57.4 FMC+ HSPC connector J22
• VITA 57.1 FMC HPC1 connector J2
• Power management with PMBus voltage monitoring through Maxim power controllers
and GUI
• 10-bit 0.2 MSPS SYSMON analog-to-digital front end
• Configuration options:
BPI linear flash memory
°
Digilent USB configuration module
°
Platform cable USB II interface 2x7 2 mm connector
°

Board Specifications

Dimensions

Height: 6.927 inch (17.59 cm)
Thickness (±5%): 0.061 inch (0.1549 cm)
Length: 9.5 inch (24.13 cm)
A 3D model of this board is not available.
Note:
The VCU118 board height exceeds the standard 4.376 inch (11.15 cm) height of a PCI
IMPORTANT:
®
Express card.

Environmental

Temperature
Operating: 0°C to +45°C
Storage: -25°C to +60°C

Humidity

10% to 90% non-condensing
