Appendix -

C: Port Forwarding

After assigning the IP Camera a web server
port and video server port use Port Forwarding.
(for cases A, B)
Consult your router's manual to properly
configure Port Forwarding.
For your convenience, we have provided two
example configurations.
1. For D-Link DI-604 broadband routers:
1) Open a web browser and type http://192.168.0.1
2) Enter your User Name and Password to
Default: User Name: admin Password: [leave blank].
3) Select the "Advanced" tab and click "Virtual Server".
1
2
4) Click "Apply" after inputting proper values.
Enabled / Disabled Select "Enabled".
Name Input IVS name.
Private IP Input IVS address.
Protocol Type Select "TCP".
Private Port / Public Port
Input IVS Web Server Port.
Schedule Select "Always"
5) If 'Setting Saved' shows, click [Continue] button.
6) Repeat these steps to add the Video Server Port.
7) The Web Server Port, Video Server Port and 2 Audio Ports
shows in "Virtual Server List" as below.
2. For Linksys BEFSR41 Cable/DSL routers:
1) Open a web browser and type http://192.168.1.1
2) Enter your User Name and Password to
Default: User Name: [leave blank] Password: admin.
3) Select "Applications & Gaming" from the menu bar.
4) Input port numbers in "Port Range" as below and click
"Save Setting". Both Web Server Port and Video Server
Port should be added.
Enabled / Disabled
3
Start / End
Protocol
IP Address
Enabled
57
4
5
6
Input IP Camera name.
Input IP Camera Web Server Port and Video
Server Port.
Start should be same as End.
Both of Web Server Port and Video Server
Port should be added.
Select "TCP" in Protocol option.
Input IP Camera IP Address.
Check the square.
