Camera Setup
Brightness
Set the brightness of the camera's image from 0~20. The higher the
number, the brighter the camera's image will appear. Default is 10.
Sharpness
Sets the image sharpness. The higher the number, the sharper the
image.
Mirror
Reverse the video from side to side.
Flip
Reverse the video from up to down.
IR LED Mode
Applied for Cameras with IR LED only.
Auto: IR will be set automatically.
Manual: IR can be set manually. 'Night' must be selected at
'Day & Night' option for manual control of IR.
Day & Night
Auto: In this mode, the IR cut filter is removed automatically
depending on the light conditions.
Day: In this mode, the IR cut filter is applied to the image sensor all
the time. Thus, the sensitivity will be reduced in the dark light
condition but better color reproduction performance are obtained.
Night: In this mode, the IR cut filter is removed from the image sensor
all the time. The sensitivity will be enhanced in the dark light
condition but the image will be in black and white.
TDN BW Level
The light levels at which the camera will switch from Day mode into
Night mode when Day & Night mode is Auto. The higher the number,
the lower the light level. This number should be lower than the value
of TDN Color Level.
TDN Color Level
The light levels at which the camera will switch from Night mode into
Day mode when Day & Night mode is Auto.
