Web Viewer Screen -
Control Tab
Speaker Control - Enable/Disable Audio stream received
9
from the camera and Volume control of the speaker in the
computer.
Mic Control - Enable/Disable the Audio stream to the camera.
10
Motion Detection - Enable or Disable motion detection
11
function. 'Area Setup' below must be set in advance.
Event Alert Icon ( ) will appear on the screen if 'Motion
Detection' is activated. Icon will remain unless 'Event Display
Clear' button is clicked.
While the motion detection is activated, this function is
de-activated momentarily if the OSD and OSD menu is shown on
the screen. It is re-activated once the OSD and OSD menu
disappear.
Sensitivity - Define the sensitivity of motion detection. If
9 12
High is selected, it will detect very small motion while it
becomes relatively insensitive when Low is selected.
10
Area Setup - Setup the target area for motion detection.
13
11
1) If 'Set' button is clicked, Live screen will display a grid to help area
12
setup.
2) By clicking or dragging mouse on the grids, create or erase the
13 masks on the main view.
3) Motion detection is effective in the masked Area.
4) Save setting by clicking 'Save' button.
Area Setup is possible only on the Ch No.1 in the 'Video Format'.
If you change the video format, motion detection area will return
the setup to its default settings.
Masked Area
Detection Effective
23
Unmasked Area
No Detection
