Setup -
Panorama Configuration
Position Adjustment
1
Adjust the video position of each individual lens.
Select a 'Cam' and adjust the position by using '-', '+' buttons.
Press 'Set' to save.
Apply to position
2
After the camera's positions have been adjusted, click 'Save'.
Restore: Restore last saved values.
Default: Restore the default value.
Vertical Position
Horizontal Start Position
Horizontal Width
If total width adjustment is down up to 1920, you may see
black video. This time, its value is set up to 1920, video is normal.
31
1
2
Cam1 Cam2 Cam3
25 12 77
193 241 189
1920 1695 1920
