Motion Detection Setup

Activation Time
1
Select activation time from Always / Only Scheduled Time.
An alarm is activated whenever motion is
Always
detected.
Only An alarm event is activated only when motion
Scheduled Time is detected during the scheduled time.
To setup schedule, you need to define Start time and End time
followed by selecting Days.
If End time is earlier than Start time, End time is regarded as next
day.
Ex) Assume you select Tue. If you set Start time as 16:00 and End
Time as 09:00, Alarm Input will work from 4:00pm Tue to
9:00 am Wed.
Action
2
Define a counter action from Alarm Output / Alarm Image
transfer when motion is detected.
Action
Turn ON / OFF Image Transfer. Send image via
Alarm Image
E-mail or FTP server. (For more detail see
Transfer
Transfer Setup in this chapter)
Alarm Output Activate alarm out (relay).
Output
Select time duration to maintain output.
Duration
"Alarm output, Output duration" can only be set with cameras
which supports alarms.
Click 'Apply' to save all changes.
3
42
1
2
3
Description
