Camera Setup -
Camera Setup
Digital Slow Shutter
Slow shutter mode decreases the speed of the shutter in low light to
improve image quality. The slower the shutter, the brighter the image.
However, this can also cause ghosting when fast motion occurs.
Gain Limit
Maximum light gain settings in low light conditions. Select from 0dB
(least light) to 41dB (most light). Default value is 41dB.
DNR
If reduces the noise caused by 'AGC' action. If set towards 'HIGH', the
noise will be reduced but the ghost effect on moving objects will be
increased.
White Balance
Auto: White Balance is set automatically based on current conditions.
Auto-Ext: White Balance is set automatically under the assumption
of special external illumination like halogen.
Indoor: White Balance is set automatically under the assumption of
indoor illumination settings.
Outdoor: White Balance is set automatically under the assumption of
outdoor illumination settings.
Preset: White Balance is fixed based on current lighting. Click 'Set'
in One push Trigger.
Manual: The R/B gain level can be set up manually.
Kelvin
Determines the warmth or coolness of the light. Select from Low,
Middle, or High. Default value is Middle.
One Push Trigger
Click 'Set' continuously until screen image attain an ideal WB.
Shutter
If Shutter is set to Auto, shutter speed is adjusted automatically
according to the surrounding illumination.
Shutter Speed
The faster the shutter speed is, moving objects will appear without
ghosting effect. However, this will also cause the picture to appear
darker if there is no sufficient lighting. This menu is activated when
Shutter is set to Manual.
LED Saturation
Control the LED Saturation.
Defog
Eliminate amount of fog on display screen.
