Digital Watchdog DWC-PV2M4T User Manual page 59

Appendix -
C: Port Forwarding
3. For Netgear RP614 routers:
1) Input http://192.168.0.1 in address bar of web browser.
http://192.168.0.1 is the default IP address.
2) Input the username and password (admin as ID and
password as password).
3) Click "Port Forwarding" in "Advanced".
4) Click " Add Custom Service" in the Port Forwarding
1
page.
1
5) Input proper values in "Ports - Custom Services" as
below.
2
Enable Check the box to activate the entry.
Service Name Input the IP camera's name.
Starting/ Input the IP camera's Web Server port.
Ending Port Starting Port should be same as Ending Port.
Server IP Address Input the IP camera's IP Address.
6) Click " Add".
2
7) With the same method as above, add Video Server Port.
8) Click "Apply" to complete Port Forwarding.
58
