Setup -
FTP Setup
To transfer/save images to a site through FTP, FTP must to be setup.
1 Use Passive Mode
Use Passive mode for FTP transfer. If this option is not checked,
the transfer will be in Active Mode. Active Mode, may
have transfer issues due to firewall settings.
Consult your network manager for more information.
FTP Server Address
2
Enter the FTP's IP address. If IP Address form is incorrect,
a Message box will appear.
Upload Path
3
Define a path in the FTP server to store the video from the
camera.
4 Port
Enter the FTP Server's Port. If Port is incorrect, it will be
impossible to access the FTP Server.
User ID
5
Enter the User ID to access the FTP Server.
Password
6
Enter the Password to access the FTP Server.
Click 'Apply' to save all changes.
7
