Ptz Control - Digital Watchdog DWC-PV2M4T User Manual

Web Viewer Screen -

PTZ Control

1
2
3
4
5
6
7 8
9
10
11 13
12 14
Pan-tilt wheel buttons - The Pan-tilt wheel enables you to
1
move the camera directions by clicking the corresponding
arrow buttons. To move the camera, click and hold the
direction arrow. To stop the camera's movement, release
the button.
Pan-tilt speed slider - The camera's pan-tilt speed is
2
controlled by clicking the ' + ' or ' - ' buttons, or by dragging
the red-lined slider in the center.
Zoom control button - Zoom in and out of the camera's
3
image by clicking the ' + ' or ' - ' buttons.
Preset Selection - View and select a preset number from the
4
drop down list.
Go Button - Move the camera to a selected preset.
5
Name Preset - Name the current preset. Max. 9 characters
6
are allowed (including space).
Set Button - Save current location at selected preset.
7
Delete Button - Delete a location of a selected preset.
8
Preset Tour - Select a Tour from the drop-won list.
9
Tour Setup - Select a preset and set the preset's dwell time
10
during the tour before moving to the next preset. At least 2
presets must be setup prior in order to properly setup a
preset tour.
Set Button - Save the current preset tour changes.
11
Go Button - Press 'Go' button to start running a tour.
12
Clear Button - Clear the selected tour settings.
13
Stop Button - Stop running the selected preset tour.
14
24
