980 DP Video Generator - User Guide
11.173

Toshiba

11.173.1 Description
Special test image developed per customer specifications. There are two sub images, the secondary image is
depicted below. The top half of the image has three small boxes (red, green, blue) with the upper left half at 92.7%
luminence and the upper right half at 50% luminence. There is a series of 11 small boxes of increasing luminence
left to right with the luminence identified in text. The lower left quarter of the image is 28.5% luminence and the
lower right is magenta at 44.3 IRE.
