MEMEPlus, MEPlus_B, MEPlus_G, and MEPlus_R

11.107.1 Description
In the primary version, the screen is filled with blue (BLU and B), green (GRN and G), red (R), or white (WHT and
Sony) EM character blocks on a black background. Only the white character has a secondary version. It is drawn
with black characters on a white background.
A bitmap of a single character block is shown here. The BLU_EM+ image is shown below.
11.107.2 Test
Focus.
11.107.3 Purpose
This pattern is specified by one or more display manufacturers for checking and adjusting focus one color at a time.
