Strokes0, Strokes1

11.166.1 Description
This image may cited by some display manufacturers' test procedures. The Strokes0 version consists of multiple
groups of separated red, green and blue horizontal lines drawn on a black background. The Strokes1 version
consists of multiple groups of separated red, green and blue diagonal lines drawn on a black background.
11.166.2 Purpose
These images are special-purpose test patterns used in test and alignment procedures specified by some display
manufacturers.
