980 DP Video Generator - User Guide
7.3.3 New Format - General Tab
The Format Editor General tab is shown below. The table that follows describes each of the fields in the tab.
7.3.4 New Format - General Tab (Top Left Panel)
The top left panel of the General tab in the Format Editor is shown below.
The table that follows describes each of the fields in the top left panel of the General tab.
Field / Entity
Horizontal
Vertical
Unit Size
Page 142
Type
Entry field
Entry field
Radio Buttons:
Description / Function
The horizontal aperture of the display under test.
The vertical aperture of the display under test.
