980 DP Video Generator - User Guide
Button
7.2.2 Format Editor – Top Level Tabs
When you select the New activation button a populated window will appear as shown below.
There are a series of tabs on the top as shown below.
The following table describes the top level tabs in the Format Editor.
Tab
Timing
Page 136
Description
button.
Description / Function
Selecting the Timing tab opens up an application screen that enables you to define the timing parameters for
a custom format or modify the timing parameters of an existing format.
