980 DP Video Generator - User Guide
Field / Entity
Digital Sync Gate
Not used for HDMI
Digital Sync Polarity
Not used for HDMI
Video Gate
Page 146
Entity Name
B
Select buttons
H
V
C
Select buttons
H
V
C
Select buttons
R
G
B
Description / Function
component.
Puts the analog composite sync on the Blue component.
Enables and disables the digital horizontal sync output.
Enables and disables the digital vertical sync output. To
use digital vertical sync, the digital separate H and V
sync must be selected.
Enables and disables the digital vertical sync output.
Determines whether the digital horizontal sync pulse
polarity is positive going or negative going.
Determines whether the digital vertical sync pulse polarity
is positive going or negative going.
Determines whether the digital composite sync pulse
polarity is positive going or negative going.
Enables you to gate ON or OFF any of the video
components. More than one can be selected.
Gates ON or OFF the Red component. Parameter:
REDG
Gates ON or OFF the Green component. Parameter:
GRNG.
Gates ON or OFF the Blue component. Parameter:
BLUG.
