980 DP Video Generator - User Guide
Heading
Bars
Page 152
Field
Signal Aspect Ratio
Extended From Content Apert. Map
Signal from Extended Apert. Map
Left
Right
Top
Bottom
Description / Function
valid parameter range is: 0.75 to 2.39.
Sets the aspect ratio of the video signal image content.
The valid parameter range is: 0.75 to 2.39.
Enables you to set the mapping type for mapping
CXAR-shaped image content into the extended
EXAR-shaped aperture.
Enables you to set the mapping type for mapping
EXAR-shaped image content into the SXAR-shaped
signal interface.
Sets the left side letterbox bars in pixels.
Sets the right side letterbox bars in pixels.
Sets the top letterbox bars in pixels.
Sets the bottom letterbox bars in pixels.
