980 DP Video Generator - User Guide
Command supported?: Y
Enables or disables activation of alternate versions of test images if they have alternate versions. Takes no parameters.
Query returns the current setting.
IMGL graysall // loads the SlideBox image
ISUB 1 // enables alternate versions of the image
IVER 1 // activates the first version of an image
IMGU // invokes the image and image version.
ISUB 0 // disables alternate versions of the image
IVER
Command supported?: Y
Enables or disables activation of alternate versions of test images if they have alternate versions. Takes no parameters.
Query returns the current setting.
IMGL graysall // loads the SlideBox image
ISUB 1 // enables alternate versions of the image
IVER 100 // activates the 100th version of the image
IMGU // invokes the image and image version.
NBPC
Command supported?: Y
Sets the number of bits per component on HDMI. Valid values are: 8 = 8 bits per component; 10 = 10 bits per component; 12
= 12 bits per component. Only affects output when color space is RGB or YCbCr 4:4:4.
Requires FMTU or ALLU to activate.
Query returns the current setting of the number of bits per component.
Example:
NBPC 12 // sets the component bit depth to 12 bits
NBPC? // returns the current value.
OUTG
Command supported?: Y
Sets the enable gate of video output. (This is defaulted to 1 – only set to 0 to disable video when absolutely necessary.)
Requires FMTU or ALLU to activate.
Query returns the current setting for the enable gate for the video.
Example:
OUTG 1 // enables the outputs.
OUTG? // returns the current setting.
REDG/GRNG/BLUG
Command supported?: Y
Enables red/green/blue, respectively. (Also see XVSG.)
Requires FMTU or ALLU to activate.
Query returns the current setting for enabling red, green, blue video.
Examples:
REDG 1 // enables the red output channel.
GRNG 0 // disables the green output channel.
BLUG 1 // enables the blue output channel.
BLUG? // returns the current setting.
SCAN
