Table Of Contents - Quantum Data 980 DP User Manual

980 DP Video Generator - User Guide
1. About the 980 DP Video Generator Module
1.1 Scope of this User Guide
1.2 Changes to this User Guide
1.3 What options are available with the 980?
1.4 980 User Interface
2. Getting Started
2.1 What is shipped with the 980 DP Video Generator module?
2.2 Operational workflow for DP Video Pattern Testing
3. Testing DP Displays with the 980 DP Video Generator module
3.1 Workflow for running the video pattern testing of DP displays
3.2 Connector Description
3.3 Making the physical DP connections
3.4 Navigating through the 980 GUI Manager interface
3.5 Selecting DP formats
3.6 Selecting formats (resolutions)
3.7 Configuring the format Settings
3.8 Selecting Test Patterns
3.9 Selecting Test Patterns Settings
3.10 Viewing the EDID of a connected display
3.11 Viewing the DPCD of a connected display
3.12 Testing HDCP on a connected display
4. DP LINK TRAINING CONTROL
4.1 Accessing the Link Training Control application
5 Auxiliary Channel Analyzer (ACA) Utilities
Aux Channel Analyzer and ACA Remote Control - For Real Time Viewing of DP Aux Channel Data
5.1
5.2 Monitoring DP Aux Chan Transactions with the ACA
5.3 Monitoring Auxiliary Channel transactions from the External 980 GUI Manager with the ACA Remote
Control panel
5.4 Viewing Stored DP Aux Chan traces on a PC with the ACA Data Viewer utility
5. Pattern List Editor
5.1 Creating a custom list of test patterns
5.2 Applying a custom Pattern List
5.3 Viewing a custom Pattern List
5.4 Opening a custom Patten List from the Pattern List Editor
6. Format List Editor
6.1 Opening a custom Format List
6.2 Applying a custom Format List
6.3 Viewing a custom Format List
6.4 Opening a custom Format List
7. Format Editor
Page 2

Table of Contents

Rev. A4
9
9
10
10
13
14
14
14
16
16
17
19
21
26
28
35
37
41
44
48
58
63
63
72
73
86
91
96
103
103
109
115
118
120
120
126
129
130
132
July 14, 2014
