DTMF Settings
Set the time period/signal length for
the DTMF Timer, First Timer,
* # Timer.
Continuous Tone
Continuous Tone
Select the desired CTCSS
frequency from the list or enter a
3-digit DTCS code with polarity,
N (Normal) or I (Inverse).
Continuous Tone Setting
Set the Continuous Tone Setting
items for Tone Burst, CTCSS
Reverse Burst Timer, etc.
Scan
Scan List
Set the scan type, primary CH, secondary CH, TX
CH, Talkback CH, Cancel CH, and Text.
Scan setting
Set the Scan Setting items for Resume,
Talk-back, Fast Scan, Slow Scan, Power
on scan etc.
Emergency
Enter up to a 24-character emergency text that will
be displayed on the LCD while the emergency
function is activated. Lone Worker Timer can also
be selected.
Cloning Items
External I/O
CH Switch Table
Available for mobile radios only.
Port Setting
The desired function can be assigned to some of
the D-sub 25 pins on the screen.
The assignable pins are:
Ext. I/O [10]/[12]/[15]/[17]/[18]/[19]/[21]/[23]/
[24] and [25]. See
for details.
Common
Key & Display
Assign the desired functions to the programmable
function keys. And set the keypad operation, beep
audio frequency, display mode 1 line or 2 lines, etc.
Set Mode
User set mode enables you to customize the
transceiver operation to suit your preferences and
operation style.
Common
Commonly set items as Clone Comment, Security,
Auto Reset, Scrambler, etc. items.
Character editor Character editor
Up to 16 original characters or symbols can be
edited/created for a variety of information
indication.
3-3 D-Sub 25 Pin Configuration
